Eaton FWH-70A High Speed Fuse - 700 Vac/dc, RoHS
Part Number: FWH-70A
Quick Summary
The Eaton FWH-70A high speed fuse provides fast overcurrent protection for 700 Vac/dc circuits in industrial control panels. Engineers often struggle with nuisance trips and downtime caused by slower fusing in motor drives and power rails. This device is RoHS compliant, and regional CE/UL verification should be confirmed with Eaton to satisfy your regulatory requirements. Its blade-end x blade-end connection and compact enclosure simplify installation in densely packed control panels, reducing maintenance time and service calls. Sourcing from the Bussmann series ensures consistent availability, streamlined cross-references, and predictable performance across your electrical protection and circuit control portfolio.
Product Information
Extended Description
FWH-70A Eaton: Eaton Bussmann series FWH high speed fuse, 700 Vac/dc, 70A, Non Indicating, High speed fuse, Blade end X blade end
Product Name
Eaton Bussmann series FWH high speed fuse
Catalog Number
FWH-70A
UPC
051712150057
Product Length/Depth
4.6 in
Product Height
1.12 in
Product Width
1.8 in
Product Weight
0.2 lb
Warranty
Not Applicable
Compliances
Contact factory RoHS Compliant
Amperage Rating
70 A
Voltage rating
700 Vac/dc
Packaging type
Standard
Connection
Blade end x blade end
Fuse indicator
Non Indicating
Feature: High current rating of 70 A with a 700 Vac/dc rating. Business Impact: Provides robust protection for high-demand industrial loads, reducing the risk of catastrophic equipment damage. Application: Ideal for motor drives, inverters, and power distribution in control panels. Feature: Fast-acting, high-speed response. Business Impact: Minimizes fault energy and arc exposure, shortening downtime and extending equipment life. Application: Protective devices in automated production lines and panel boards. Feature: Blade end x blade end connections. Business Impact: Enables quick, secure installation with minimal wiring effort, improving field service efficiency. Application: Replacement in standard Bussmann blade-end fuse holders and similar assemblies. Feature: Non-indicating fuse. Business Impact: Lowers upfront costs and simplifies panel design where visual indication is managed separately. Application: Dense control panels with integrated indication schemes. Feature: RoHS compliance. Business Impact: Supports regulatory compliance and sustainable manufacturing practices, reducing environmental risk. Application: Global deployments where RoHS is required or preferred. Feature: Standard packaging. Business Impact: Streamlines stocking, procurement, and shelf-life management across multi-site operations. Application: Inventory planning for spare parts and drop-in replacements in the Bussmann series.
Get a Quick Quote for a Eaton FWH-70A
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton FWH-70A?
Enquire Now
FAQs
The FWH-70A uses blade end x blade end connections, enabling quick insertion into standard blade-end fuse holders. Ensure panel cutouts and spacing meet your enclosure specifications, and verify compatibility with Bussmann series catalog references to simplify ordering and spare-parts management.
The fuse is rated for 70 A and supports 700 Vac/dc, making it suitable for high-demand AC and DC circuits. Ideal applications include motor drives, inverters, and power distribution within industrial control panels where fast fault clearing is critical.
Yes, the FWH-70A is RoHS compliant. Depending on regional requirements, verify CE/UL and other local approvals with Eaton to ensure full regulatory compliance for your installation site.
High-speed protection reduces selective fuse energy during fault events, lowering the risk of equipment damage and arc exposure. This translates to fewer unplanned downtimes and reduced maintenance costs over the life of motor drives and control systems.
The FWH-70A is part of the Bussmann series. Cross-reference with Eaton Bussmann catalogs and use the catalog number FWH-70A for ordering, with multiple downloadable catalogs and datasheets available for quick reference and replacement planning.
