Eaton FWH-90A High Speed Fuse - 700 Vac/dc, 90 A
Part Number: FWH-90A
Quick Summary
Eaton FWH-90A high speed fuse protects electrical circuits in industrial controls and motor drives. Engineers rely on fast-acting devices to prevent equipment damage and downtime in high-current 700 Vac/dc systems. Note: The data sheet does not list SIL, CE, or IP certifications, but RoHS compliance supports environmental responsibility and regulatory alignment. The 90 A rating paired with stud mounting delivers rugged, field-friendly installation in control panels and power cabinets. This fuse simplifies procurement and minimizes panel redesigns by using standard Bussmann hardware and a compact footprint. Businesses benefit from reduced downtime, clearer fault localization, and predictable maintenance planning when protecting critical loads in automation and machinery.
Product Information
Extended Description
FWH-90A Eaton: Eaton Bussmann series FWH high speed fuse, 700 Vac/dc, 90A, Non Indicating, High speed fuse, Stud
Product Name
Eaton Bussmann series FWH high speed fuse
Catalog Number
FWH-90A
UPC
051712150071
Product Length/Depth
4.6 in
Product Height
1.12 in
Product Width
1.8 in
Product Weight
0.2 lb
Warranty
Not Applicable
Compliances
Contact factory RoHS Compliant
Amperage Rating
90 A
Voltage rating
700 Vac/dc
Packaging type
Standard
Fuse indicator
Non Indicating
Mounting method
Stud
Bussmann series complete full line catalog no. 1007
Bussmann series complete full line catalog no. 1007
Eaton Specification Sheet - FWH-90A
Feature: High speed interruption. Business Impact: Rapid fault isolation minimizes collateral damage and reduces mean time to repair (MTTR) in automated lines. Application: Motor drives and power distribution where fast clearing is critical. Feature: 90 A at 700 Vac/dc. Business Impact: Consistent protection across AC and DC networks, enabling safer, cleaner shutdowns without nuisance trips. Application: Heavy-duty industrial controls and machinery hubs where simultaneous AC/DC protection is required. Feature: Stud mounting. Business Impact: Robust mechanical and electrical connection supports vibration-prone environments and simplifies field installation. Application: Panel builders and OEMs integrating through-bus or terminal blocks. Feature: Non-indicating design. Business Impact: Reduced panel complexity and cost; fewer o-ring indicators and wiring clutter. Application: Compact control panels where visual fault indicators aren’t needed. Feature: RoHS compliant. Business Impact: Supports regulatory compliance and sustainability goals, easing procurement for regulated industries. Application: Aviation, automotive, and general industrial automation where environmental standards matter. Feature: Standard packaging and catalog readiness. Business Impact: Faster BOM completion and easier stocking through Bussmann ecosystem. Application: OEMs and maintenance teams seeking predictable lead times and supply chain reliability.
Get a Quick Quote for a Eaton FWH-90A
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton FWH-90A?
Enquire Now
FAQs
To install the FWH-90A, secure it using the stud mounting into a compatible fuse holder or terminal block designed for high-current Bussmann devices. Ensure clean, tight connections, proper insulation, and adherence to NEC guidelines. After mounting, verify continuity and confirm that the circuit protection settings match the 90 A rating before energizing the panel.
The FWH-90A is ideal for industrial control panels, motor drive circuits, and power distribution nodes that require fast fault interruption at 90 A and up to 700 Vac/dc. It pairs well with rugged process machinery, HVAC controls, and other high-current environments where reliable, rapid protection minimizes equipment damage and downtime.
The FWH-90A offers a high speed interrupt with a 700 Vac/dc rating and a 90 A current rating in a stud-mount package, enabling robust, vibration-tolerant installations. Its non-indicating design reduces panel clutter, while RoHS compliance supports regulatory and environmental requirements, making it suitable for modern automation environments.
Yes, the FWH-90A is RoHS compliant, meaning it meets environmental and materials restrictions that minimize hazardous substances. This helps ensure compliance with European and global sustainability standards, simplifies supplier audits, and supports greener manufacturing practices without compromising protection performance.
You can access the Eaton Bussmann datasheet for FWH-90A on Eaton’s site (Eaton Specification Sheet - FWH-90A) and reference the Bussmann series catalog no. 1007 for broader product context. Additional catalog links are available in the product downloads section, including a full line PDF and related specifications.
