Eaton FWH5-016A6FR High Speed Fuse - CSA Certified
Part Number: FWH5-016A6FR
Quick Summary
Eaton FWH5-016A6FR high speed fuse protects control panels and motor drives. When protection trips are mis-timed, downtime and maintenance costs rise. CSA Certified, RoHS Compliant, and rated for 500 V, 16 A with a 50 kAIC interrupt rating, it supports safe, compliant operation in industrial environments. For OEMs and maintenance teams, this fuse delivers reliable protection with a compact form factor, enabling faster commissioning, easier spare-part planning, and reduced risk of costly outages across electrical protection & circuit control applications.
Product Information
Extended Description
FWH5-016A6FR Eaton: Eaton Bussmann series FWH high speed fuse, Electric engineering, 500V, 16A, 50 kAIC, Non Indicating, High speed fuse - FWH5-016A6FR
Product Name
Eaton Bussmann series FWH high speed fuse
Catalog Number
FWH5-016A6FR
UPC
051712531979
Product Length/Depth
13.5 in
Product Height
10.1 in
Product Width
11.4 in
Product Weight
31.8 lb
Warranty
Not Applicable
Compliances
RoHS Compliant
Certifications
CSA Certified
Amperage Rating
16 A
Interrupt rating
50 kAIC
Voltage rating
500 V
Packaging type
Standard
Fuse indicator
Non Indicating
Special features
Electric engineering
FWH5-016A6FR~BUSS, HIGH SPEED FUSE RoHS
FWH5-016A6FR~BUSS, HIGH SPEED FUSE RoHS
Eaton Specification Sheet - FWH5-016A6FR
Feature: 50 kAIC interrupt rating and 500 V rating provide robust fault current protection. Business Impact: minimizes arc energy and protects downstream equipment, reducing the risk of collateral damage. Application: ideal for feeders and control circuits in industrial panels. Feature: Non-indicating design reduces panel clutter and simplifies status monitoring when used with external indicators. Business Impact: cleaner control enclosures and easier visual inspection during maintenance. Application: suitable for OEM dashboards and modular installations in automation lines. Feature: RoHS compliant and CSA certified for regulatory compliance and safety assurance. Business Impact: supports sustainable manufacturing and North American safety standards, reducing compliance risk. Application: appropriate for industrial protection & circuit control deployments in regulated environments. Feature: 16 A current rating matches many control circuits and motor drives, helping limit nuisance trips. Business Impact: improves uptime and equipment reliability by preventing overprotection. Application: common in motor control centers and programmable logic controller (PLC) fed circuits. Feature: Standard packaging and compatibility with Eaton Bussmann FWH series streamline procurement and installation. Business Impact: shorter onboarding, easier stocking, and faster maintenance cycles. Application: fits into existing Bussmann series protection schemes in industrial panels.
Get a Quick Quote for a Eaton FWH5-016A6FR
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton FWH5-016A6FR?
Enquire Now
FAQs
The fuse provides 50 kAIC interrupt capacity at 500 V, enabling safe disconnection of high fault currents in industrial equipment.
Yes, the device is RoHS compliant and CSA certified, meeting environmental and North American safety standards.
It is rated for 500 V with an amperage rating of 16 A, suitable for protecting typical control circuits and motor drives.
Ideal for electrical protection and circuit control in industrial panels, motor drives, and OEM equipment within automation and protection applications.
No, the FWH5-016A6FR is non-indicating; external indicators can be added if status visibility is required.
