Eaton FWP-45 High Speed Fuse - 250 Vac/dc, Non Indicating
Part Number: FWP-45
Quick Summary
Eaton FWP-45 high speed fuse provides fast interruption for industrial control circuits in drives, panels, and machines. Engineers often face nuisance trips and tight maintenance windows that disrupt production; this fuse helps minimize those interruptions while delivering reliable protection. While the product page lists a 250 Vac/dc rating and standard packaging, exact certification details require factory confirmation. In practice, Bussmann series fuses are aligned with common industry standards and tested for robust performance in electrical protection and circuit protection applications. For automation projects, the combination of a compact form factor, a standard catalog footprint, and a non-indicating option supports streamlined procurement and faster field replacements, reducing downtime and inventory complexity.
Product Information
Extended Description
FWP-45 Eaton: Eaton Bussmann series FWP high speed fuse, 250 Vac/dc, Standard Pkg, Non Indicating
Product Name
Eaton Bussmann series FWP high speed fuse
Catalog Number
FWP-45
UPC
051712508674
Product Length/Depth
0.75 in
Product Height
4.35 in
Product Width
0.75 in
Product Weight
0.18 lb
Warranty
Not Applicable
Compliances
Contact factory Contact Manufacturer
Voltage rating
250 Vac/dc
Packaging type
Standard
Fuse indicator
Non Indicating
Feature: 250 Vac/dc rating provides broad compatibility with AC and DC control circuits in industrial equipment. Business Impact: Enables reliable fuse protection across mixed-signal drives and controllers, reducing the risk of uncontrolled faults. Application: Suitable for control panels and machine interfaces where fast interruption is critical. Feature: Compact footprint with 0.75 in length and 0.75 in width (4.35 in height) optimizes panel real estate. Business Impact: Saves enclosure space, allows denser wiring, and simplifies retrofits in crowded electrical cabinets. Application: Rapid deployment in existing automation racks and new panel builds. Feature: Non Indicating fuse indicator simplifies maintenance. Business Impact: Eliminates indicator wiring and visual status checks, lowering wiring complexity and potential misreads during servicing. Application: Standard protection blocks in automated lines where indicators are not required. Feature: Standard packaging supports efficient procurement. Business Impact: Improves spare parts availability and reduces lead times for outages. Application: Centralized stocking in OEM and contract manufacturers. Feature: Catalog compatibility with Bussmann series provides broad availability and datasheets. Business Impact: Accelerates design validation with access to technical datasheets and catalogs for sizing and replacement. Application: Design and field engineering workflows in factory automation and electrical protection planning.
Get a Quick Quote for a Eaton FWP-45
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton FWP-45?
Enquire Now
FAQs
The FWP-45 is designed for 250 Vac/dc circuits and fits standard Bussmann-series protection schemes. It uses a compact 0.75 in length by 0.75 in width form factor with a 4.35 in height, making it suitable for control panels, drives, and automation racks. For installation, verify panel space, torque requirements on terminations, and ensure the catalog references match FWP-45 before sourcing spares.
The FWP-45 is a high speed fuse intended to rapidly interrupt in fault conditions, protecting sensitive electronics and control circuitry. This results in faster fault isolation and reduced damage to downstream components. It is offered in standard packaging and a non-indicating variant, which simplifies panel wiring. Use this fuse where rapid clearance of short-circuit faults is critical to uptime.
Yes, with a 250 Vac/dc rating and a compact form factor, the FWP-45 is well-suited for industrial automation applications, including drives, PLC panels, and machine control interfaces. Its high-speed interruption helps prevent cascading faults, while standard packaging supports efficient stocking. Confirm the exact load currents and replacement intervals in your system design datasheets.
The product page lists compliance as ‘Contact factory / Contact Manufacturer,’ so explicit certifications are not published here. For regulatory alignment, request current certification documentation from Eaton, and consult the accompanying datasheets or catalogs for UL/IEC/CE references typically associated with Bussmann-series fuses. Always verify the latest certified status before mission-critical deployments.
Adopt a maintenance strategy that keeps a quantity of readily available spares based on historical fault rates in your lines. The FWP-45’s standard packaging and non-indicating design simplify stocking and replacement. By coordinating with your preventive maintenance plan and ensuring quick field swaps, you reduce downtime costs and improve line throughput while maintaining consistent protection across control circuits.
