Eaton FWP-50A High Speed Fuse - RoHS Compliant
Part Number: FWP-50A
Quick Summary
FWP-50A high speed fuse provides fast interruption to protect electrical circuits in industrial control panels. Engineers frequently battle nuisance trips and downtime when protection is too slow or misapplied to the circuit load. RoHS compliant construction helps streamline regulatory compliance, while the 50 A at 250 Vac/dc rating covers a broad range of loads. For panel builders and OEMs, this fuse delivers reliable, readily sourced protection with straightforward installation, reducing maintenance and spare parts requirements. That also translates to greater uptime in demanding automation environments.
Product Information
Extended Description
FWP-50A Eaton: Eaton Bussmann series FWP high speed fuse, 250 Vac/dc, 50A, Non Indicating, High speed fuse, Stud
Product Name
Eaton Bussmann series FWP high speed fuse
Catalog Number
FWP-50A
UPC
051712150293
Product Length/Depth
4.6 in
Product Height
1.12 in
Product Width
1.8 in
Product Weight
0.24 lb
Warranty
Not Applicable
Compliances
Contact factory RoHS Compliant
Amperage Rating
50 A
Voltage rating
250 Vac/dc
Packaging type
Standard
Fuse indicator
Non Indicating
Mounting method
Stud
Bussmann series complete full line catalog no. 1007
Bussmann series complete full line catalog no. 1007
Eaton Specification Sheet - FWP-50A
Feature: High-speed fuse topology delivers ultra-fast interruption. Business Impact: Limits arc energy and protects downstream equipment during short-circuit events. Application: Motor drives, power distribution, and control panels in industrial settings. The result is reduced downtime and lower repair costs. Feature: 50 A, 250 Vac/dc rating. Business Impact: Provides clear, defined protection for typical loads, enabling safe cross-compatibility across AC and DC circuits. Application: General protection in OEM equipment and factory automation. The outcome is consistent protection and simplified engineering. Feature: Non-indicating design. Business Impact: Eliminates the need for fuse status indicators in crowded or vibration-prone enclosures, lowering maintenance costs. Application: Panel interiors where remote indication is provided elsewhere. Feature: Stud mounting. Business Impact: Quick, secure installation with robust electrical contact and resistance to vibration. Application: Industrial control panels and equipment racks. The benefit is faster commissioning and reliable service life. Feature: RoHS compliant. Business Impact: Facilitates regulatory compliance across multinational deployments, reducing risk during audits. Application: Machinery, robotics, and automation equipment. Feature: Compact form factor and standard packaging. Business Impact: Fits tight panel spaces and standard enclosure layouts, reducing design changes and installation time. Application: Space-constrained control panels and device enclosures. Outcome: Lower total cost of ownership through efficient stocking and maintenance.
Get a Quick Quote for a Eaton FWP-50A
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton FWP-50A?
Enquire Now
FAQs
Installation uses the stud terminals provided on the fuse body. Align the fuse with the panel opening, connect the stud to the appropriate bus bar or terminal lug, and tighten to the manufacturer’s recommended torque. Ensure proper clearances around the fuse body to accommodate heat dissipation and vibration resistance in industrial environments.
The 50 A amperage rating specifies the maximum continuous current the fuse can protect. The 250 Vac/dc rating indicates suitability for both AC and DC circuits up to 250 volts. In practice, this supports protection for typical industrial loads such as motors, drives, and control circuits while maintaining fast interruption behavior.
Yes, the FWP-50A is RoHS compliant, meaning it adheres to restrictions on hazardous substances for electronics assemblies. This simplifies regulatory compliance across many regions and supports safer, easier integration into modern machinery and panel builds.
Best suited for industrial control panels, motor drives, and power distribution nodes where fast fault clearance is critical. The non-indicating, stud-mounted design plus compact footprint supports retrofit projects and space-constrained enclosures, enabling reliable protection with straightforward sourcing for OEMs and maintenance teams.
Key dimensions are 4.6 inches in length, 1.8 inches in width, and 1.12 inches in height, with an approximate weight of 0.24 lb. The fuse uses a standard packaging type and stud mounting, making it compatible with common panel layouts and mounting hardware used in industrial electrical protection schemes.
