Eaton FWP-70A High Speed Fuse - Stud Mount, 70A, 250 Vac/DC
Part Number: FWP-70A
Quick Summary
The Eaton FWP-70A High Speed Fuse protects electrical circuits by rapidly interrupting fault currents in industrial power and control panels. End users often face nuisance trips and extended downtime when protection devices aren’t fast enough to isolate faults. RoHS compliant and designed as a non-indicating, stud-mounted fuse, it supports reliable integration in rugged industrial environments and simplifies compliance documentation. With a 70 A rating and a 250 Vac/dc voltage capability, it enables efficient protection for motor drives, power supplies, and automation cabinets while keeping panel size and weight manageable.
Product Information
Extended Description
FWP-70A Eaton: Eaton Bussmann series FWP high speed fuse, 250 Vac/dc, 70A, Non Indicating, High speed fuse, Stud
Product Name
Eaton Bussmann series FWP high speed fuse
Catalog Number
FWP-70A
UPC
051712150323
Product Length/Depth
4.59 in
Product Height
1.35 in
Product Width
1.32 in
Product Weight
0.39 lb
Warranty
Not Applicable
Compliances
Contact factory RoHS Compliant
Amperage Rating
70 A
Voltage rating
250 Vac/dc
Packaging type
Standard
Fuse indicator
Non Indicating
Mounting method
Stud
Feature: High-speed interrupting action delivers rapid fault isolation. Business Impact: This minimizes collateral damage to downstream equipment and reduces downtime expenses. Application: Ideal for motor drives and power supplies in automation cabinets where fast clearance is critical. Feature: 70 A amperage rating and 250 Vac/dc voltage rating. Business Impact: Supports protection across both AC and DC circuits, reducing component replacement and service calls. Application: Widely applicable in industrial control panels and power distribution enclosures. Feature: Stud mounting for secure installation. Business Impact: Enhances mechanical stability in vibration-prone environments and simplifies mounting on standard Bussmann series bus bars. Application: Panel assemblies and equipment racks in harsh industrial settings. Feature: Non-indicating fuse. Business Impact: Minimizes visual indicators in crowded control panels, reducing confusion during maintenance. Application: Control cabinets where external signaling is provided by separate indicators. Feature: RoHS compliant. Business Impact: Supports regulatory compliance and streamlined sourcing for electronics manufacturing. Application: OEM panel builds and retrofits requiring eco-friendly components. Feature: Compact dimensions and standard packaging. Business Impact: Saves panel space and simplifies stocking with a consistent Bussmann line footprint. Application: Dense control panels, compact machines, and service stock programs.
Get a Quick Quote for a Eaton FWP-70A
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton FWP-70A?
Enquire Now
FAQs
The FWP-70A uses stud mounting for secure attachment to standard bussing and panel assemblies. Its compact footprint (4.59 in L, 1.32 in W, 1.35 in H) and light weight (0.39 lb) simplify installation in crowded control panels and support durable performance in vibration-prone environments.
Best suited for industrial automation cabinets, motor drives, and power supply enclosures where rapid fault isolation is critical. The 70 A rating paired with a 250 Vac/dc capacity makes it a versatile protection solution across both AC and DC circuits in distribution panels.
The FWP-70A is RoHS compliant, aligning with eco-friendly manufacturing standards. Additional regulatory certifications may be available through Eaton on request; consult the datasheet or contact the manufacturer for full certification coverage specific to your region or application.
Its high-speed operation reduces the likelihood of extensive damage during faults, shortening downtime and improving mean time between failures. The fuse’s standard Bussmann series footprint also simplifies stocking and replacements, reducing maintenance inventory complexity.
With a 250 Vac/dc rating, the FWP-70A protects both AC and DC circuits. Ensure the circuit current does not exceed 70 A and consider whether your panel requires a non-indicating fuse for your fault-finding workflow or external signaling is provided elsewhere in the system.
