Eaton FWX-175A High Speed Fuse - UL Recognized
Part Number: FWX-175A
Quick Summary
Eaton FWX-175A high speed fuse protects industrial power circuits and motor drives in automation and controls. Users often struggle with nuisance trips and equipment damage from overcurrents in dynamic plant environments. UL Recognized, CSA Certified, and CE Marked along with RoHS compliance provide regulatory confidence, while 600 V rating and 175 A RMS capability address demanding control panels. This solution delivers reliable electrical protection with fast interruption, helping you reduce downtime and extend equipment life while meeting procurement and safety requirements. In practice, it supports streamlined maintenance, safer installations, and consistent performance across evolving automation architectures.
Product Information
Extended Description
FWX-175A Eaton: Eaton Bussmann series FWX high speed fuse, 600V, 175A RMS, 200 kAIC Vac, 50 kAIC at 250 Vdc, Non Indicating, High speed fuse, Blade end X blade end, Stud
Product Name
Eaton Bussmann series FWX high speed fuse
Catalog Number
FWX-175A
UPC
051712150668
Product Length/Depth
3.11 in
Product Height
3.11 in
Product Width
1.23 in
Product Weight
0.3 lb
Warranty
Not Applicable
Compliances
CE Marked RoHS Compliant
Certifications
UL Recognized CSA Certified
Amperage Rating
175A RMS
Interrupt rating
200 kAIC Vac 50 kAIC at 250 Vdc
Voltage rating
600 V
Watt losses
18.5 W
Packaging type
Standard
Connection
Blade end x blade end
Fuse indicator
Non Indicating
Mounting method
Stud
Bussmann series complete full line catalog no. 1007
Eaton Specification Sheet - FWX-175A
FWX-175A~BUSS HIGH SPEED FUSE
FWX-175A~BUSS HIGH SPEED FUSE
Datasheet - FNQ-30
Feature → Business Impact → Application: The FWX-175A offers a 600 V, 175 A RMS fast-acting profile with a 200 kAIC Vac interrupt rating and 50 kAIC at 250 Vdc, enabling precise protection for high-energy control circuits; result is minimized arc-flash risk and reduced downtime in motor drives and power panels. Application: Industrial automation cabinets and machine control centers that demand swift fault isolation without nuisance tripping. Feature → Business Impact → Application: Blade end x blade end connections with stud mounting provide versatile, secure installs in tight panel spaces; benefit is lower installation time and greater reliability in harsh environments. Application: Retrofit projects and new builds in food & beverage, packaging, and process automation. Feature → Business Impact → Application: Non-indicating design reduces panel clutter and simplifies component sourcing while delivering proven protection; use where indication is managed by upstream diagnostics. Application: Standard control panels requiring robust protection with clean aesthetics. Feature → Business Impact → Application: Compliance through UL Recognized, CSA Certified, CE Marked, RoHS; impact is easier supplier qualification and audit readiness. Application: Environments with strict regulatory demands and supplier qualification processes.
Get a Quick Quote for a Eaton FWX-175A
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton FWX-175A?
Enquire Now
FAQs
The FWX-175A uses blade end x blade end connections for quick inline wiring and a stud mounting option for secure panel mounting. Ensure proper torque on studs per Eaton datasheet, verify voltage rating is within system limits, and route conductors to minimize thermal buildup. This simplifies retrofit projects and new installations alike.
FWX-175A is rated 600 V and offers 200 kAIC at AC, with 50 kAIC at 250 Vdc. It can be used on DC circuits rated within 250 V and within its DC interrupt capability. For high-energy DC circuits, confirm the DC interrupt rating and consult the datasheet to ensure safe and compliant operation.
FWX-175A carries UL Recognized and CSA Certified marks, and CE and RoHS compliance. These certifications support supplier qualification, regulatory audits, and safer procurement in regulated industries such as manufacturing, food processing, and energy infrastructure.
With a 200 kAIC AC interrupt rating and 175 A RMS rating, the FWX-175A provides rapid protection against short circuits in motor drives and power panels. This mitigates fault current damage, reduces downtime, and improves overall system reliability in demanding automation environments.
The device measures 3.11 in length and height, 1.23 in in width, and weighs 0.3 lb. It uses blade end x blade end connections and supports stud mounting, making it compatible with standard Bussmann/FWX line configurations and common control panel layouts.
