Eaton FWX-275A High Speed Fuse - 200 kAIC Vac
Part Number: FWX-275A
Quick Summary
The Eaton FWX-275A high speed fuse delivers fast-acting overcurrent protection for industrial control panels and motor drives. It addresses the pain of nuisance trips and prolonged fault recovery by clearing faults quickly and reliably. This device is RoHS compliant and designed to meet demanding electrical protection standards, with an interrupt rating of 200 kAIC Vac and 50 kAIC at 250 Vdc. Even with its high performance, the FWX-275A remains compact and easy to install, reducing panel space and wiring complexity. With blade-end x blade-end connections and stud mounting, it supports flexible installation in new builds or upgrades while aligning with Bussmann FWX series protection strategies. Its non-indicating design keeps panel layouts tidy and simplifies field diagnostics.
Product Information
Extended Description
FWX-275A Eaton: Eaton Bussmann series FWX high speed fuse, 200 kAIC Vac, 50 kAIC at 250 Vdc, Non Indicating, High speed fuse, Blade end X blade end, Stud
Product Name
Eaton Bussmann series FWX high speed fuse
Catalog Number
FWX-275A
UPC
051712153980
Product Length/Depth
4.3 in
Product Height
1.63 in
Product Width
1.62 in
Product Weight
0.46 lb
Warranty
Not Applicable
Compliances
Contact factory RoHS Compliant
Interrupt rating
200 kAIC Vac 50 kAIC at 250 Vdc
Packaging type
Standard
Connection
Blade end x blade end
Fuse indicator
Non Indicating
Mounting method
Stud
Bussmann series complete full line catalog no. 1007
Eaton Specification Sheet - FWX-275A
Bussmann series FWX 35-2500A high speed fuses data sheet no. 720005
Bussmann series FWX 35-2500A high speed fuses data sheet no. 720005
Datasheet - FNQ-30
200 kAIC Vac interrupt rating provides a wide fault-current margin, enabling rapid fault clearance in heavy-use AC circuits. This translates to reduced arc energy, less collateral damage, and longer equipment life in drives and feeders. The FWX-275A is well-suited for motor control centers and power distribution assemblies where swift isolation is critical. 50 kAIC at 250 Vdc expands protection for DC buses in drives and battery-connected power structures, helping prevent DC arc burns and protecting semiconductor devices during switching transients. Blade end x blade end connections combined with stud mounting simplify installation and replacement in existing panel blocks, reducing retrofit time and minimizing rewiring while enabling flexible protection strategy alignment. Compact dimensions—4.3 in L, 1.63 in H, 1.62 in W—and a weight of 0.46 lb support installation in crowded panels and compact fuse blocks. RoHS compliance and standard packaging ease procurement and regulatory alignment, while the non-indicating design keeps wiring clean and supports scalable protection with Eaton Bussmann FWX components.
