Eaton HCLR1 Fuse - Fast Acting Class CC, 600 V, 200 kAIC
Part Number: HCLR1
Quick Summary
The Eaton HCLR1 fuse is a fast-acting protection device for lighting circuits. Engineers often struggle with nuisance trips and selecting the right rating for sensitive loads in control panels. This CE marked, RoHS compliant fuse delivers reliable 200 kAIC interrupt capability at 600 V, while its Class CC, non-indicating design offers compact, predictable protection. With Eaton Edison branding, the HCLR1 aligns with Edison fuse families for consistent stocking, compatibility, and procurement efficiency in both new builds and retrofits. The product supports reliable protection of lighting and resistance-heating circuits, while simplifying maintenance and regulatory compliance for industrial electrical systems.
Product Information
Extended Description
HCLR1 Eaton: Eaton Edison HCLR fuse, Fast acting branch circuit fuse, Rejection style, Non-inductive loads, Lighting, resistance heating circuits, 1 A, Class CC, Non-indicating, 200 kAIC, Nickel-plated brass endcaps, Melamine tube, Standard, 10, 600 V
Product Name
Eaton Edison HCLR fuse
Catalog Number
HCLR1
UPC
782634420583
Product Length/Depth
1 in
Product Height
0.406 in
Product Width
0.406 in
Product Weight
0.1 lb
Warranty
Not Applicable
Compliances
CE Marked RoHS Compliant
Amperage Rating
1 A
Interrupt rating
200 kAIC
Voltage rating
600 V
Material
Melamine tube Nickel-plated brass endcaps
Packaging type
Standard
Class
Class CC
Fuse indicator
Non-indicating
Quantity
10
Special features
Rejection style
Feature: Fast-acting design delivers rapid interruption during fault events, reducing energy damage and downtime. Business Impact: Minimizes arc flash exposure and equipment wear, improving overall line reliability. Application: Ideal for 1 A non-inductive loads in lighting and small branch circuits, where fast clearing is critical. Feature: Rejection style construction prevents incorrect insertion, reducing panel misfeeds and accidental fuse removal. Business Impact: Lowers maintenance calls and replacement costs, especially in high-mix panel environments. Application: Suitable for standard Class CC fuse holders in control cabinets. Feature: Class CC, 1 A, non-indicating fuse with 600 V rating and 200 kAIC interrupt rating. Business Impact: Provides predictable protection for low-current loads with high fault withstand, enabling safer panel operation. Application: Common in lighting and resistance heating circuits across commercial and industrial facilities. Feature: Melamine tube with nickel-plated brass endcaps delivers mechanical robustness and reliable electrical contact. Business Impact: Extends service life in vibration-prone environments and reduces contact resistance over time. Application: Applies to compact fusing solutions within Eaton Edison power distribution. Feature: Packaging of 10 units per standard package supports strategic stocking and faster replacements. Business Impact: Improves maintenance planning and reduces downtime during outages. Application: Useful in OEM assemblies and field service inventories, especially where single-use fuses are common. Feature: RoHS and CE compliance ensures regulatory readiness and safer disposal. Business Impact: Simplifies procurement for regulated facilities and promotes sustainable practices. Application: Aligns with European market requirements and global electrical installations.
