Eaton HCLR5 Edison fuse - 200 kAIC
Part Number: HCLR5
Quick Summary
Eaton HCLR5 Edison fuse is a fast-acting branch circuit protector designed for lighting and control circuits. In compact panel installations, selecting a device that delivers reliable protection without nuisance trips can be a challenge. This fuse lineup carries CE marked and RoHS compliant certifications, along with Class CC construction and a 200 kAIC interrupt rating to ensure dependable performance. By aligning with Eaton's Edison series, you gain consistent sourcing, standard packaging, and straightforward replacement, helping reduce downtime and inventory complexity in your control and lighting applications.
Product Information
Extended Description
HCLR5 Eaton: Eaton Edison HCLR fuse, Fast acting branch circuit fuse, Rejection style, Non-inductive loads, Lighting, resistance heating circuits, 5 A, Class CC, Non-indicating, 200 kAIC, Melamine tube, Nickel-plated brass endcaps, Standard, 10, 600 V
Product Name
Eaton Edison HCLR fuse
Catalog Number
HCLR5
UPC
782634420644
Product Length/Depth
1 in
Product Height
0.406 in
Product Width
0.406 in
Product Weight
0.1 lb
Warranty
Not Applicable
Compliances
CE Marked RoHS Compliant
Amperage Rating
5 A
Interrupt rating
200 kAIC
Voltage rating
600 V
Material
Nickel-plated brass endcaps Melamine tube
Packaging type
Standard
Class
Class CC
Fuse indicator
Non-indicating
Quantity
10
Special features
Rejection style
Feature: 5 A, 600 V, 200 kAIC rating with Class CC, non-indicating design. Business Impact: Provides precise protection with fast interruption for sensitive loads, minimizing collateral damage and downtime. Application: Lighting and resistance heating circuits in compact control panels. Feature: Rejection-style construction and melamine tube with nickel-plated brass endcaps. Business Impact: Robust mechanical integrity and reliable performance in challenging environments, reducing maintenance frequency. Application: Industrial panel boards and machine control enclosures. Feature: Standard packaging of 10 units per package. Business Impact: Streamlined stocking, faster replacement, and improved procurement efficiency for maintenance teams. Application: Daily field and repair operations. Feature: CE Marked and RoHS compliant. Business Impact: Compliance assurance across European markets and reduced environmental impact. Application: Any regional installations requiring formal certification. Feature: Non-indicating fuse with compact dimensions (1 in length, 0.406 in width and height). Business Impact: Easy visual integration into dense panel layouts and compatibility with standard fuse blocks. Application: Panel density-constrained installations and retrofit projects.
Get a Quick Quote for a Eaton HCLR5
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton HCLR5?
Enquire Now
FAQs
HCLR5 is a standard Edison-style fast-acting fuse designed for common branch circuit blocks in lighting and control panels. It measures 1 in in length with 0.406 in width and height, and uses non-indicating, rejection-style construction for straightforward drop-in replacement in compatible housings.
The HCLR5 provides a 5 A amperage rating, a 600 V voltage rating, and a 200 kAIC interrupt rating. These specs support reliable protection for non-inductive loads while enabling rapid fault clearance in a compact form factor.
Yes. The HCLR5 is explicitly described as suitable for non-inductive loads including lighting and resistance heating circuits, delivering fast protection with minimal disruption to normal operation.
The HCLR5 is CE marked and RoHS compliant, with a Class CC fuse design. These certifications help ensure regulatory compliance in European markets and align with sustainability requirements while maintaining reliable electrical protection.
The HCLR5 reduces downtime through fast fault interruption and reliable performance, supports efficient stocking with standard packaging of ten per pack, and simplifies sourcing with a consistent Edison-series family. These factors collectively lower maintenance costs and improve overall panel uptime.
