Eaton HCTR6 Edison fuse - 200 kAIC, 600 V, Class CC
Part Number: HCTR6
Quick Summary
The Eaton HCTR6 Edison fuse provides reliable current-limiting protection for industrial control circuits and panel installations. Engineers often struggle with nuisance tripping from inrush or short-circuit events that stress panels and drives. This device is CE-marked and RoHS compliant, rated at 600 V with a 200 kAIC interrupt capability. Its compact 1 in length and standard packaging simplify retrofits and replacements across equipment fleets, minimizing downtime. With Class CC, non-indicating design and a rejection-style construction, it delivers predictable protection and easy stocking for automation projects.
Product Information
Extended Description
HCTR6 Eaton: Eaton Edison HCTR fuse, Current-limiting high inrush, Rejection style, 6 A, Class CC, Non-indicating, 12 sec at 200%, 200 kAIC, Nickel-plated brass endcaps, Melamine tube, Standard, 10, 600 V
Product Name
Eaton Edison HCTR fuse
Catalog Number
HCTR6
UPC
782634802242
Product Length/Depth
1 in
Product Height
0.406 in
Product Width
0.406 in
Product Weight
0.1 lb
Warranty
Not Applicable
Compliances
CE Marked RoHS Compliant
Amperage Rating
6 A
Interrupt rating
200 kAIC
Response time
12 sec at 200%
Voltage rating
600 V
Material
Melamine tube Nickel-plated brass endcaps
Packaging type
Standard
Class
Class CC
Fuse indicator
Non-indicating
Quantity
10
Special features
Rejection style
Feature: Current-limiting with high inrush tolerance. Benefit: Reduces arc energy and equipment wear, lowering maintenance costs and提升 overall system reliability. Application: Industrial control panels and motor feeders where inrush peaks are common. Feature: 6 A ampacity with 600 V rating and 200 kAIC interrupt capability. Benefit: Strong short-circuit protection that safeguards downstream devices while supporting compact panel design. Application: Machine control circuits and distribution blocks in harsh industrial environments. Feature: Rejection style, Class CC, melamine tube with nickel-plated brass endcaps. Benefit: Safer insertion, robust durability, and long service life in demanding applications. Application: Standard Edison fuse holders and replacement in automation cabinets. Feature: Standard packaging, quantity 10, compact dimensions (1 in length, 0.406 in width, 0.406 in height). Benefit: Easy stocking, quick swaps, and streamlined procurement for scalable projects. Application: Large facilities requiring consistent spares and rapid maintenance. Feature: CE Marked and RoHS compliant. Benefit: Regulatory compliance across global operations, simplifying cross-border sourcing and project deployment. Application: Global manufacturing lines and multi-site automation deployments.
Get a Quick Quote for a Eaton HCTR6
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton HCTR6?
Enquire Now
FAQs
Yes. The HCTR6 is a Class CC Edison fuse designed for standard Edison fuse holders used in industrial panels. Its 1 in length and 0.406 in cross-section permit straightforward retrofits, installation in compact cabinets, and reliable compatibility with existing protection schemes in control circuits.
The HCTR6 is rated for 6 A and 600 V with a 200 kAIC interrupt rating. It provides current-limiting protection, with a time characteristic of approximately 12 seconds at 200% overload, making it suitable for high inrush applications while preserving downstream equipment.
Current-limiting Edison fuses quickly suppress fault currents, reducing arc energy and protecting motors, drives, and control electronics. They improve uptime, minimize collateral damage during faults, and support smaller, more cost-effective panel designs by allowing higher fault currents without excessive disruption.
The HCTR6 is CE-marked and RoHS compliant, aligning with essential regulatory standards for global manufacturing and distribution. This ensures compliance across European markets and cleaner material compositions, reducing the risk of non-conformances in multi-site projects and facilitating smoother procurement processes.
Each pack includes 10 fuses. The device measures 1 inch in length with a width and height of 0.406 inches, and it weighs about 0.1 lb. The fuse uses a melamine tube with nickel-plated brass endcaps, offering durable construction suitable for standard protection applications in industrial cabinets.
