Eaton HCU2080D7N2 Active Harmonic Correction Unit-IEEE 519
Part Number: HCU2080D7N2
Quick Summary
The Eaton HCU2080D7N2 Active Harmonic Correction unit mitigates harmonic distortion in three-phase, 690 V industrial power systems. Operators confront bulky, high-cost filters and slow tuning; this solution provides precise correction with a floor-mount NEMA 2 enclosure designed for rugged factory environments. It meets IEC 61000-3-2, IEC 61000-3-4, IEEE Std. 519, UL 508C, and CSA C22.2 No. 14, delivering recognized safety and grid-compliance. With installation integrated into existing drives and switchgear, it unlocks tangible business value by improving power quality, boosting efficiency, and reducing ongoing maintenance costs. This combination supports proactive procurement and reliability, helping factories meet performance targets.
Product Information
Extended Description
HCU2080D7N2 Eaton: Eaton Active Harmonic Correction unit, 80A, 4.5 kW watt loss, 690V rating, 50/60 Hz, Three-phase, Floor-mount, NEMA 2 enclosure
Product Name
Eaton HCU2 active harmonic correction unit
Catalog Number
HCU2080D7N2
UPC
786689640934
Product Length/Depth
57.18 in
Product Height
88.24 in
Product Width
25.69 in
Product Weight
1473 lb
Certifications
IEC 61000 3-2 IEC 61000-3-4 IEEE Std. 519 UL 508C CSA Std. C22.2 No. 14
Product Category
Harmonic Correction Units
Amperage Rating
80 A
Enclosure
NEMA 2
Frequency rating
50/60 Hz
Mounting
Floor
Phase
Three-phase
Type
Active Harmonic Correction unit
Voltage rating
690 V
Watt losses
4.5 kW
Feature is an active harmonic correction unit with an 80 A amperage rating and 4.5 kW watt losses, delivering targeted harmonic mitigation for 690 V three-phase systems. Business impact is improved power quality and grid compliance, enabling cleaner energy use and reduced penalties; applications include data centers, manufacturing lines, and heavy industry drives. Feature floor-mount installation in a robust NEMA 2 enclosure simplifies retrofits and new builds, reducing space planning and integration time while increasing overall reliability. Feature certifications to IEC 61000-3-2, IEC 61000-3-4, IEEE Std. 519, UL 508C, and CSA No. 14 support safe operation and regulatory alignment; application context includes controlled environments and regulated facilities. Feature footprint and weight, 57.18 in length, 88.24 in height, 25.69 in width, and 1473 lb, enable predictable floor space planning for manufacturing floors and data centers. Feature 50/60 Hz operation and 690 V rating ensure compatibility with typical industrial feeders and motor drives, reducing the need for additional voltage conditioning hardware.
