Eaton HCUN020Y4N1 Harmonic Correction Unit - UL Type 1
Part Number: HCUN020Y4N1
Quick Summary
Eaton HCUN020Y4N1 active harmonic correction unit reduces harmonic distortion in three-phase industrial power systems. A common pain point is overheating and efficiency loss from unmanaged harmonics, which can trigger nuisance trips and shorten equipment life. UL Type 1 enclosure rating supports indoor wall-mounted installations; for global deployments, verify regional certifications such as CE or IP ratings as applicable. This solution integrates with existing controllers and automation infrastructure, delivering measurable power quality improvements, reduced energy waste, and lower maintenance costs. By addressing harmonics at the source, it offers a clear path to improved reliability in automation lines and data-center-like environments, while keeping installation straightforward for plant engineers and maintenance teams.
Product Information
Extended Description
HCUN020Y4N1 Eaton: Eaton active harmonic correction unit, HCUn 20A 208-415Vac 3ph+N wall mount UL Type 1
Product Name
Eaton HCU2 active harmonic correction unit
Catalog Number
HCUN020Y4N1
UPC
786689646431
Product Length/Depth
29 in
Product Height
28 in
Product Width
69.5 in
Product Weight
280 lb
Product Category
Harmonic Correction Units
Amperage Rating
20 A
Mounting
Wall
Phase
Three-phase
Type
Active Harmonic Correction unit
Voltage rating
208-415 Vac
The HCUN020Y4N1 active harmonic correction unit delivers targeted harmonic mitigation, resulting in lower THD and improved system efficiency, which translates to reduced energy waste and cooler running equipment. This directly supports better motor performance and longer asset life in demanding manufacturing environments, while helping facilities meet power quality standards. The unit’s 208-415 Vac three-phase input and 20 A rating enable flexible integration with mid-size feeders, supporting scalable automation projects without overhauling existing power infrastructure. Its wall-mount enclosure saves valuable floor space in control rooms and electrical rooms, facilitating easier installation and service access in tight plant layouts. UL Type 1 compliance provides indoor-safety confidence, simplifying regulatory alignment for standard industrial applications. Combined with robust cabinet construction, the HCUN020Y4N1 offers reliable, long-term operation in busy industrial facilities.
Get a Quick Quote for a Eaton HCUN020Y4N1
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton HCUN020Y4N1?
Enquire Now
FAQs
HCUN020Y4N1 is designed for indoor, wall-mounted installations in three-phase electrical systems typical of manufacturing floors, data centers, and HVAC applications. It handles up to 20 A at 208-415 Vac, providing effective harmonic correction in compact control spaces. Ensure adequate clearance for service access and cooling within UL Type 1 compliant enclosures.
The unit actively corrects harmonic currents by injecting compensating signals, lowering total harmonic distortion (THD) and improving power factor. This reduces heat generation, minimizes equipment wear, and decreases nuisance trips. In practice, users experience more stable motor operation, enhanced system efficiency, and reduced maintenance needs across automation and processing lines.
Yes. HCUN020Y4N1 is designed for indoor wall-mount use with UL Type 1 enclosure protection. Installation considerations include ensuring sufficient space around the cabinet for ventilation and service access. The system is configured for three-phase plus neutral operation at 208-415 Vac, supporting typical industrial power distribution layouts.
Model HCUN020Y4N1 supports 20 A with a voltage rating of 208-415 Vac in a three-phase plus neutral configuration. It is a wall-mounted harmonic correction unit within the Harmonic Correction Units category, weighing 280 lb, with dimensions approximately 69.5 in wide, 28 in high, and 29 in deep. The UPC is 786689646431, and the enclosure is UL Type 1.
By reducing harmonic losses and overheating, the HCUN020Y4N1 can lower energy costs and extend motor life, contributing to a favorable ROI in mid-to-large manufacturing settings. Maintenance needs are typically reduced since corrective harmonics limit stress on drives and power electronics. A targeted installation in appropriate lines yields quicker payback, with ongoing benefits from improved reliability and uptime.
