Eaton HEL20434CGR1N Meter Pack - UL Listed, ANSI 61
Part Number: HEL20434CGR1N
Quick Summary
Eaton B-Line meter pack is a robust horizontal mounting solution for power distribution in industrial facilities. Engineers often face tight spaces, complex wire routing, and restricted maintenance access, which slow projects and raise risk. This unit addresses those challenges with a ringless cover, accessible 5-position design, and lever bypass for quick service. It carries UL certification and features an ANSI 61 gray finish on durable aluminum, ensuring both safety and corrosion resistance in demanding environments. By combining compact footprint with high-capacity 200A operation, it fits modern electrical rooms while supporting scalable metering. In practice, it delivers reliable metering alongside straightforward installation and lower lifecycle costs for building owners and integrators.
Product Information
Extended Description
HEL20434CGR1N Eaton: Eaton B-Line series horizontal meter pack, Ringless, ANSI 61 gray paint, Aluminum, #6 AWG-350 KCMIL, 5, 3, 200A, Lever, 4
Product Name
Eaton B-Line series horizontal meter pack
Catalog Number
HEL20434CGR1N
UPC
782051397758
Product Length/Depth
6.625 in
Product Height
25 in
Product Width
5.25 in
Product Weight
117.841 lb
Certifications
UL
Amperage Rating
200A
Material
Aluminum
Finish
ANSI 61 gray paint
Number of jaws
4
Number of wires
3
Bypass
Lever
Number of positions
5
Load lug size
#6 AWG-350 KCMIL
Cover/door type
Ringless
Feature: 200A amperage rating with 4 jaws and 3-wire capacity. Business Impact: Supports heavy feeders and versatile metering configurations, enabling compliant distribution within a single enclosure. Application: Ideal for commercial/industrial meter installations integrated into Eaton B-Line series systems. The result is faster project timelines and reduced wiring errors. Feature: Aluminum body with ANSI 61 gray paint. Business Impact: Provides corrosion resistance and long-term durability in harsh environments, lowering maintenance costs. Application: Suitable for indoor and outdoor electrical rooms and damp locations. Feature: Ringless cover design. Business Impact: Speeds up wiring and service access, minimizing downtime during installations or upgrades. Application: Beneficial for retrofits and equipment room rearrangements. Feature: Load lug size of #6 AWG-350 KCMIL. Business Impact: Enables termination of large-diameter conductors with a secure, code-compliant connection, reducing splices. Application: Feeder and service conductors in high-capacity metering. Feature: Lever bypass with 5-position configuration. Business Impact: Allows service continuity during maintenance without full disconnection, improving uptime. Application: Maintenance workflows and testing scenarios. Feature: Dimensions and weight (25 in H, 6.625 in L, 5.25 in W, 117.841 lb). Business Impact: Informs enclosure sizing, mounting hardware selection, and space planning. Application: Field installations in constrained electrical rooms. Feature: UL certification. Business Impact: Provides safety assurance and meets regulatory expectations for building codes and commissioning. Application: Utility-scale and facility metering projects requiring certified components.
Get a Quick Quote for a Eaton HEL20434CGR1N
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton HEL20434CGR1N?
Enquire Now
FAQs
The HEL20434CGR1N is designed for seamless integration with Eaton B-Line series meter mounting equipment, featuring a ringless cover, four jaws, and a three-wire configuration that aligns with common metering schemes. Its 200A rating and #6 AWG-350 KCMIL load lug capability support typical feeder and service conductor terminations, reducing the need for adapters or rewiring during retrofits.
Plan for a vertical clearance that accommodates a 25 in height and 6.625 in depth, with a 5.25 in width footprint. The lever bypass enables service without full disconnection, and the ringless cover simplifies wiring access. Ensure UL-listed components are used in accordance with local codes and that #6 AWG-350 KCMIL conductors are terminated using appropriate lug hardware.
Yes. The unit uses durable aluminum with ANSI 61 gray finish and carries UL certification, supporting safety and corrosion resistance in demanding environments. Its 200A rating and robust construction make it appropriate for commercial and light-industrial metering applications, including spaces exposed to variable temperatures and humidity where protected enclosures are required.
The HEL20434CGR1N is UL-listed, which signifies compliance with recognized safety standards for electrical equipment. This certification is crucial for meeting code requirements in most jurisdictions and for ensuring reliability during commissioning, maintenance, and inspections in both new builds and retrofit projects.
The enclosure’s ringless design and lever bypass reduce installation and maintenance time, lowering labor costs. The ability to terminate large conductors with #6 AWG-350 KCMIL minimizes splicing and related hardware, while the UL-certified aluminum construction reduces corrosion-related downtime, contributing to lower lifecycle costs and improved system uptime.
