Eaton HLS-02 Fuse Holder - CE Marked RoHS Compliant, 2-Pole
Part Number: HLS-02
Quick Summary
Eaton HLS-02 fuse holder provides reliable fuse protection for electrical control panels. In tight enclosures, space constraints and the need for durable, corrosion-resistant terminations are common challenges for engineers and technicians. This unit carries CE marking and RoHS compliance to meet EU safety and environmental standards, while its two-pole design and tin-plated bifurcated copper terminals support robust connections in demanding environments. For panel builders and maintenance teams, the compact form factor and compatibility with GMT Type Indicating Series translate to faster commissioning, easier service, and lower total cost of ownership. By selecting the HLS-02, you leverage a proven Bussmann series component that aligns with standard industrial practices and supplier ecosystems.
Product Information
Extended Description
HLS-02 Eaton: Eaton Bussmann series HLS fuse holder, No flanges, 125 Vac, 60 Vdc, 15 A, Two-pole, Tin-plated bifrucated copper terminal
Product Name
Eaton Bussmann series HLS fuse holder
Catalog Number
HLS-02
UPC
051712169905
Product Length/Depth
0.001 in
Product Height
0.001 in
Product Width
0.001 in
Product Weight
5.5 lb
Warranty
Not Applicable
Compliances
CE Marked RoHS Compliant
Amperage Rating
15 A
Voltage rating
125 Vac, 60 Vdc
Material
Tin-plated bifurcated copper terminal
Number of Poles
Two-pole
Special features
No flanges
Used with
Used with GMT Type Indicating Series
Bussmann series complete full line catalog no. 1007
Bussmann series complete full line catalog no. 1007
Bussmann series Fuseology
Eaton Specification Sheet - HLS-02
Feature: No flanges simplify mounting in crowded control panels and reduce hardware requirements. Business Impact: Faster installation and fewer parts to source in constrained spaces. Application: Ideal for GMT Type Indicating Series installations where a compact fit is critical. Feature: Two-pole design provides straightforward wiring for dual-line fuse protection. Business Impact: Improves wiring clarity and reduces risk of misconnection, enabling quicker turnarounds during service. Application: Suitable for dual-channel control circuits in industrial equipment. Feature: 15 A, 125 Vac / 60 Vdc electrical rating. Business Impact: Supports common control circuits and mixed AC/DC environments, lowering component count. Application: Practical for general machine protection and control panels. Feature: Tin-plated bifurcated copper terminals. Business Impact: Delivers durable, low-resistance connections with resistance to corrosion under vibration. Application: Harsh industrial environments and high-duty cycle applications. Feature: Compatibility with GMT Type Indicating Series. Business Impact: Enables seamless status indication integration for faster diagnostics. Application: Visual fault identification within complex panel architectures. Feature: CE Marked and RoHS compliant. Business Impact: Ensures regulatory alignment and environmental compliance, reducing risk and audit findings. Application: EU-based deployments and supplier-standard projects.
Get a Quick Quote for a Eaton HLS-02
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton HLS-02?
Enquire Now
FAQs
To install the HLS-02, mount the fuse holder in the designated panel area without requiring flanges, then connect the tin-plated bifurcated copper terminals per the wiring diagram. Ensure the two-pole design aligns with the protected circuit, secure all connections, and verify continuity with a multimeter. The GMT Type Indicating Series compatibility simplifies status indication once mounted.
The HLS-02 is rated for 15 A with 125 Vac and 60 Vdc. It uses tin-plated bifurcated copper terminals designed for reliable, low-resistance connections. The device is a two-pole fuse holder, with no flanges, optimized for compact panel spaces and straightforward wiring.
Yes. The HLS-02 carries CE marking and RoHS compliance, ensuring alignment with EU safety, environmental, and product-safety standards. This makes it a compliant choice for European control panels and downstream integrations in regulated industries.
Applications include general electrical protection in control panels, especially where GMT Type Indicating Series is used for quick visual diagnostics. Its compact, no-flanges design supports installations in tight spaces, while the 15 A rating covers many typical machine protection scenarios in automation and manufacturing.
The HLS-02 promotes faster commissioning due to its compact form and straightforward wiring, reducing labor costs. Robust, corrosion-resistant terminals lower replacement frequency in harsh environments, while CE RoHS compliance minimizes regulatory risk and streamlines procurement across EU facilities.
