Eaton HLT-04 Fuse Holder - RoHS & CE Marked
Part Number: HLT-04
Quick Summary
The Eaton HLT-04 fuse holder provides secure, compact fuse mounting for control panels and electrical enclosures. Engineers often contend with limited wiring access and the need for reliable fuse retention in space-constrained panels. It carries RoHS compliance and CE marking to support regulatory and environmental obligations. Rated for 125 Vac / 60 Vdc and 15 A, the four-pole design integrates with the GMT Type Indicating Series to streamline diagnostics and replacement. The combination supports safer electrical protection in industrial control environments while enabling predictable maintenance cycles and lower downtime. With its tin-plated bifurcated copper terminals and compact footprint, it delivers a practical balance of reliability and serviceability for panel builders.
Product Information
Extended Description
HLT-04 Eaton: Eaton Bussmann series HLT fuse holder, 125 Vac, 60 Vdc, 15 A, Four-pole, Tin-plated bifrucated copper terminal
Product Name
Eaton Bussmann series HLT fuse holder
Catalog Number
HLT-04
UPC
051712170086
Product Length/Depth
2.5 in
Product Height
1 in
Product Width
1.5 in
Product Weight
0.7 lb
Warranty
Not Applicable
Compliances
RoHS Compliant CE Marked
Amperage Rating
15 A
Voltage rating
125 Vac, 60 Vdc
Material
Tin-plated bifurcated copper terminal
Number of Poles
Four-pole
Used with
Used with GMT Type Indicating Series
Bussmann series complete full line catalog no. 1007
Bussmann series complete full line catalog no. 1007
Bussmann series Fuseology
Eaton Specification Sheet - HLT-04
Four-pole design reduces panel footprint and simplifies harnessing, delivering cleaner layouts and faster assembly in machine controls. The device supports reliable, multi-circuit protection for complex control panels, improving wiring organization and reducing fault pathways. Electrical ratings of 15 A at 125 Vac / 60 Vdc provide predictable protection for common automation circuits, enabling engineers to select one component for mixed-voltage protection. Tin-plated bifurcated copper terminals offer durable, low-resistance connections with corrosion resistance, reducing maintenance needs in vibratory environments. RoHS compliant and CE marked ensures global regulatory compliance, minimizing procurement risk across international projects. Compact dimensions—2.5 in L, 1 in H, 1.5 in W—and a 0.7 lb weight support higher panel density without sacrificing reliability. GMT Type Indicating Series compatibility enables streamlined diagnostics and consistent BOM integration. Easy wiring and installation reduce field service time and error-prone rework in tight enclosures.
Get a Quick Quote for a Eaton HLT-04
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton HLT-04?
Enquire Now
FAQs
The HLT-04 is a four-pole fuse holder designed for vertical or horizontal panel mounting. Use standard mounting hardware and connect wires to the tin-plated bifurcated copper terminals. The GMT Type Indicating Series compatibility simplifies integration into existing panel BOMs and diagnostics, ensuring proper fit and reliable connections in industrial environments.
The device is rated for 15 A, with a voltage rating of 125 Vac and 60 Vdc, making it suitable for a wide range of control circuits in mixed-voltage applications common in industrial automation.
Yes. The HLT-04 is specified as used with the GMT Type Indicating Series, enabling seamless diagnostics, consistent installation practices, and easier maintenance within that indication ecosystem.
The HLT-04 carries RoHS compliance and CE marking, supporting environmental and regulatory requirements for global deployments.
The four-pole design, robust tin-plated terminals, and GMT compatibility reduce wiring complexity, expedite installation, and lower maintenance downtime, delivering predictable protection and faster service for industrial control panels.
