Eaton HLT-06 Fuse Holder - CE Marked RoHS Compliant
Part Number: HLT-06
Quick Summary
The Eaton HLT-06 fuse holder provides six-pole fuse mounting for Bussmann fuses in electrical protection panels. This addresses field maintenance challenges by delivering secure terminations and reliable operation in compact enclosures. It carries CE marking and RoHS compliance, aligning with essential safety and environmental standards for modern facilities. Designed for GMT Type Indicating Series compatibility, the HLT-06 supports efficient panel assembly and regulatory compliance. For engineers and buyers, this translates to easier installation and lower lifecycle costs in medium to large protection projects. Its tin-plated copper terminals and six-pole configuration enable durable, low-resistance connections in demanding environments.
Product Information
Extended Description
HLT-06 Eaton: Eaton Bussmann series HLT fuse holder, 125 Vac, 60 Vdc, 15 A, Six-pole, Tin-plated bifrucated copper terminal
Product Name
Eaton Bussmann series HLT fuse holder
Catalog Number
HLT-06
UPC
051712170147
Product Length/Depth
2.5 in
Product Height
1 in
Product Width
1.5 in
Product Weight
0.7 lb
Warranty
Not Applicable
Compliances
CE Marked RoHS Compliant
Amperage Rating
15 A
Voltage rating
125 Vac, 60 Vdc
Material
Tin-plated bifurcated copper terminal
Number of Poles
Six-pole
Used with
Used with GMT Type Indicating Series
Bussmann series complete full line catalog no. 1007
Bussmann series complete full line catalog no. 1007
Bussmann series Fuseology
Eaton Specification Sheet - HLT-06
Six-pole configuration reduces panel footprint and wiring complexity, enabling consolidated fuse protection across multiple circuits with a single mounting footprint. This translates to faster assembly, improved traceability, and lower installation costs in control panels. The 15 A, 125 Vac / 60 Vdc rating covers common industrial AC and DC applications, delivering reliable performance across mixed supply environments and helping maintain uptime. Tin-plated bifurcated copper terminals provide corrosion resistance and durable, low-resistance terminations, resulting in stable electrical contact and reduced maintenance. Compact dimensions—2.5 in length, 1 in height, 1.5 in width—facilitate use in tight enclosures without sacrificing performance. CE and RoHS compliance support regulatory alignment, simplifying procurement for global deployments. GMT Type Indicating Series compatibility ensures straightforward integration with existing signaling and status indications in industrial systems.
Get a Quick Quote for a Eaton HLT-06
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton HLT-06?
Enquire Now
FAQs
The HLT-06 provides a six-pole mounting arrangement designed for Bussmann fuses and is compatible with GMT Type Indicating Series. It uses tin-plated bifurcated copper terminals for secure terminations, and its 2.5 in length, 1 in height, and 1.5 in width support compact panel layouts. When wiring, follow standard practice for low-resistance connections and verify secure seating of the fuse blocks to maintain reliable protection.
Yes. The HLT-06 is CE marked and RoHS compliant, ensuring conformity with European safety and environmental standards. This supports regulatory alignment for global deployments and reduces the need for separate certifications in many environments, facilitating smoother procurement and faster project approvals.
The HLT-06 is designed for electrical protection in industrial control panels, particularly where multiple fuse paths are required within a compact footprint. Its six-pole design and GMT Type Indicating Series compatibility make it ideal for systems needing reliable protection across several circuits while preserving space and simplifying maintenance in demanding environments.
The HLT-06 is specified for use with GMT Type Indicating Series, which streamlines integration in indication-focused assemblies. This compatibility allows engineers to maintain consistent signaling alongside fuse protection, enabling faster fault identification and more straightforward field service without disrupting the protection scheme.
Key specs include a six-pole design, 15 A rating, 125 Vac and 60 Vdc voltage ratings, and tin-plated bifurcated copper terminals. Physical dimensions are 2.5 in long, 1 in high, and 1.5 in wide, with an approximate weight of 0.7 lb. These attributes influence enclosure fit, wiring enclosure, and thermal management considerations in panel design.
