Eaton HM modular fuse block HM25060-2SCR - CR
Part Number: HM25060-2SCR
Quick Summary
The Eaton HM modular fuse block is a reliable protection device for automated control panels and equipment. Engineers often face downtime when protection blocks don’t fit existing panel layouts or require complex retrofits, and this module offers a compact, screw-terminal solution to streamline installations. UL Listed, CSA Certified, and RoHS compliant, it meets rigorous safety and environmental standards. With a 60 A, 250 V rating and the CR feature, this block supports fast, predictable protection in demanding industrial environments while reducing wiring effort and maintenance costs over the life of the panel.
Product Information
Extended Description
HM25060-2SCR Eaton: Eaton Bussmann series HM modular fuse block, CR, 60 A, Two-pole, 120, Celsius, -40, Celsius, Screw, 75 °C, Thermoplastic base, Tin-plated aluminum terminals, 250 V
Product Name
Eaton Bussmann series HM modular fuse block
Catalog Number
HM25060-2SCR
UPC
051712697699
Product Length/Depth
4.2 in
Product Height
2.24 in
Product Width
2.66 in
Product Weight
0.3 lb
Warranty
Not Applicable
Compliances
RoHS Compliant
Certifications
UL Listed CSA Certified
Amperage Rating
60 A
Voltage rating
250 V
Conductor material rated for
Both
Material
Tin-plated aluminum terminals Thermoplastic base
Number of Poles
Two-pole
Operating temperature - max
120 °C
Operating temperature - min
-40 °C
Connection
Screw
Special features
CR
Bussmann series complete full line catalog no. 1007
Bussmann series complete full line catalog no. 1007
Bussmann series Fuseology
Bussmann series Fuseology
Eaton Specification Sheet - HM25060-2SCR
Feature → Business Impact → Application: The HM25060-2SCR uses a compact two-pole design with screw connections, reducing panel footprint and simplifying wiring, which translates to faster install times and lower labour costs on new builds or retrofits in automation cabinets. Feature → Business Impact → Application: Tin-plated aluminum terminals and a durable thermoplastic base provide dependable conductivity and resilience in harsh environments, improving uptime for machine protection in packaging, material handling, and process lines. Feature → Business Impact → Application: A 60 A, 250 V rating with a wide operating temperature range (-40 °C to 120 °C) supports reliable protection across demanding climates and control loops, minimizing nuisance trips and ensuring consistent performance in hot factories and cold warehouses. Feature → Business Impact → Application: The CR feature plus RoHS, UL Listed, and CSA Certified compliance reduces regulatory risk for global installations, enabling rapid acceptance in multi-country projects and easing procurement. Feature → Business Impact → Application: Easy maintenance and compatibility with Bussmann HM series catalogs streamline component replacement and stock management for spare parts programs in panel houses and OEM environments.
Get a Quick Quote for a Eaton HM25060-2SCR
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton HM25060-2SCR?
Enquire Now
FAQs
The HM25060-2SCR uses screw connections with tin-plated aluminum terminals mounted on a thermoplastic base. This design supports secure, vibration-resistant terminations suitable for standardized panel builds and retrofit projects in industrial automation without requiring exotic tools or complex wiring schemes.
The HM25060-2SCR is a two-pole fuse block rated for 60 A and 250 V. It uses screw termination and is designed for reliability in enclosure protection, offering robust current handling and voltage rating appropriate for control circuits and small machine protection.
This module is ideal for automation panels, machine controls, and industrial equipment protection. Its compact footprint, two-pole design, and CR feature make it well-suited for packaging, material handling, and process automation environments where reliable fusing and quick retrofits are required.
HM25060-2SCR carries UL Listed and CSA Certified marks and RoHS compliance. These certifications confirm safety and regulatory alignment for North American markets and support compliance with environmental and waste-reduction standards, reducing sourcing risk in cross-border projects.
The rugged tin-plated terminals and durable thermoplastic base resist wear in demanding environments, lowering maintenance needs. A compact, screw-terminal design reduces installation time and spare-part variety, contributing to lower total cost of ownership through fewer field failures and simpler stock management in OEM and maintenance operations.
