Eaton HM60030-1CR Fuse Block - UL Listed 600V 10 kAIC
Part Number: HM60030-1CR
Quick Summary
The Eaton HM60030-1CR modular fuse block provides reliable overcurrent protection for 1-pole circuits in industrial control panels. For engineers facing space constraints, the compact footprint and straightforward replacement workflow reduce panel depth, simplify wire routing, and shorten commissioning time during upgrades or new builds. Certified UL Listed and CSA Certified with RoHS compliance, it meets essential safety, regulatory, and environmental standards for modern manufacturing environments. Its 0–30 A range, 600 V rating, and 10 kAIC short-circuit capability support scalable protection schemes, while Class H and Class K compatibility expands fuse options without reengineering the panel. This combination delivers predictable protection, easier sourcing, and lower total cost of ownership across industrial applications.
Product Information
Extended Description
HM60030-1CR Eaton: Eaton Bussmann series HM modular fuse block, CR, 0-30 A, Single-pole, Class H, Class K, 10 kAIC, 600 V
Product Name
Eaton Bussmann series HM modular fuse block
Catalog Number
HM60030-1CR
UPC
051712511452
Product Length/Depth
0.001 in
Product Height
0.001 in
Product Width
0.001 in
Product Weight
0.1 lb
Warranty
Not Applicable
Compliances
RoHS Compliant
Certifications
Contact Manufacturer UL Listed CSA Certified
Amperage Rating
0-30A
Short-circuit rating
10 kA
Voltage rating
600 V
Number of Poles
Single-pole
Class
Class H Class K
Special features
CR
HM60030-1CR~Fuse Block, Class H, 600V 30A, 1 Pole
HM60030-1CR~Fuse Block, Class H, 600V 30A, 1 Pole
Class H(K), J and R Power distribution fuse block overview
Class H(K), J and R Power distribution fuse block overview
Eaton Specification Sheet - HM60030-1CR
Amperage range and voltage rating provide precise protection for 1-pole circuits in demanding environments, enabling engineers to tailor protection to motor starts and control logic power without oversizing components. This directly reduces energy waste, limits nuisance trips, and enhances uptime in automated lines where reliable protection is non-negotiable. The 0–30 A capacity supports common Bussmann HM class fuses, allowing seamless integration with existing HM series inventories and procurement processes. In practice, technicians experience faster fuse changes and less panel downtime during maintenance, which translates to increased production throughput in machine shops and assembly lines. The 600 V rating ensures compatibility with standard industrial distribution schemes, while maintaining safety margins during fault conditions and short-time operations.
Get a Quick Quote for a Eaton HM60030-1CR
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton HM60030-1CR?
Enquire Now
FAQs
When wiring the HM60030-1CR, ensure correct alignment with the 1-pole fuse holder design and observe the 600 V rating. Use compatible Class H or Class K fuses within the 0–30 A range and verify the short-circuit rating of 10 kAIC in your upstream protection scheme. The compact form factor reduces panel depth and simplifies wire routing, speeding up panel assembly and commissioning.
The HM60030-1CR is designed to accommodate Class H and Class K protection schemes, enabling users to select the appropriate fuse type for their protection philosophy without reconfiguring the panel. This flexibility simplifies migration from one fuse class to another, reduces spares diversity, and helps maintain consistent fault-clearing performance across different motor loads and control circuits.
UL Listed and CSA Certified markings indicate compliance with widely accepted safety and performance standards for electrical protection devices. RoHS compliance ensures restricted hazardous substances are minimized in the product, supporting environmental and regulatory requirements in many manufacturing facilities. These certifications simplify procurement audits and help maintain regulatory alignment across global operations.
A 10 kAIC short-circuit rating means the fuse block can safely interrupt high fault currents without internal damage, preserving the integrity of downstream equipment and reducing the risk of cascading failures. In practice, this enables robust protection for power distribution blocks, motor drives, and control logic circuits in demanding industrial environments, improving system reliability and maintenance predictability.
The HM60030-1CR offers easy fuse replacement and compatibility with established HM series inventories, reducing spare parts variety and ordering complexity. Its compact footprint, reliable UL/CSA safety assurances, and RoHS compliance translate to less downtime during maintenance, faster changeouts, and a lower total cost of ownership over the equipment’s lifecycle in automated production lines.
