Eaton HM60030-3SR Fuse Block - UL Listed, 600V
Part Number: HM60030-3SR
Quick Summary
The Eaton HM60030-3SR fuse block provides modular three-pole protection for industrial control panels. Engineers often struggle with crowded panels and wiring complexity, making quick protection and easy replacement a must. It combines RoHS compliance with UL Listed and CSA Certified approvals, giving confidence for regulatory audits and customer requirements. The unit supports Class H and Class K fuse types and a 0–30 A rating at up to 600 V, delivering reliable protection without occupying excessive panel space. Its compact footprint and straightforward installation help reduce assembly time, minimize downtime, and simplify spare parts management across automotive, process, and machine-building applications worldwide.
Product Information
Extended Description
HM60030-3SR Eaton: Eaton Bussmann series HM modular fuse block, 0-30 A, Three-pole, Class K, Class H, 10 kAIC, 600 V
Product Name
Eaton Bussmann series HM modular fuse block
Catalog Number
HM60030-3SR
UPC
051712511414
Product Length/Depth
6.2 in
Product Height
2.25 in
Product Width
3.48 in
Product Weight
0.45 lb
Warranty
Not Applicable
Compliances
RoHS Compliant
Certifications
Contact Manufacturer UL Listed CSA Certified
Amperage Rating
0-30A
Short-circuit rating
10 kA
Voltage rating
600 V
Number of Poles
Three-pole
Class
Class K Class H
HM60030-3SR~Fuse Block, Class H, 600V 30A, 3 Pole
HM60030-3SR~Fuse Block, Class H, 600V 30A, 3 Pole
Class H(K), J and R Power distribution fuse block overview
Class H(K), J and R Power distribution fuse block overview
Eaton Specification Sheet - HM60030-3SR
Modular three-pole design enables precise protection for each phase, reducing mis-wiring risk and simplifying fuse replacement. This arrangement minimizes cross-channel faults and speeds maintenance in motor control centers and automated machinery. The HM60030-3SR integrates with the broader Eaton Bussmann HM family, ensuring consistent performance and labeling. Its compact form supports easy installation in tight control panels without sacrificing ease of access to individual fuses. With an amperage range of 0–30 A and a voltage rating up to 600 V, it improves protection selectivity and safety in demanding industrial circuits. The 10 kAIC short-circuit rating provides robust fault handling during motor startups and large inrush events, reducing the risk of downstream equipment damage. Engineers gain clear fault isolation and faster troubleshooting thanks to the three-pole architecture. RoHS compliance, UL Listed, and CSA Certified approvals support regulatory compliance and customer requirements across global supply chains. This helps procurement teams reduce audit surprises and simplifies vendor qualification. In addition, Class H and Class K compatibility expands fuse sourcing options while preserving protection integrity. The physical footprint is designed for space-constrained panels: 6.2 inches long, 3.48 inches wide, and 2.25 inches tall, with an approximate weight of 0.45 pounds. The low mass aids vibration resistance in industrial environments and assists with thermal management by minimizing heat buildup from mounting. Compatibility with Class H and Class K fuses ensures easy stocking and quick cross-reference with existing Bussmann catalog items. The three-pole format supports parallel protection strategies and simplifies wiring schemes for multi-phase circuits. Installation is straightforward—connectors and terminals align with standard panel wiring practices, enabling faster deployment and reduced commissioning time.
Get a Quick Quote for a Eaton HM60030-3SR
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton HM60030-3SR?
Enquire Now
FAQs
Install the HM60030-3SR in a suitable control panel enclosure using its compact three-pole footprint. Verify the panel space aligns with the 6.2 in length, 3.48 in width, and 2.25 in height dimensions, then mount securely. Wire the 0–30 A rated conductors to the block’s terminals, ensuring proper insulation and clear labeling for each phase. Confirm RoHS compliance and ensure UL Listed/CSA Certified status are acknowledged in your documentation. Finally, inspect for proper fuse type compatibility (Class H or K) and verify there are no loose connections to minimize heat buildup and ensure reliable operation.
The HM60030-3SR provides 0–30 A protection with a 600 V voltage rating and a 10 kAIC short-circuit rating. It is a three-pole modular fuse block designed to accommodate Class H and Class K fuses. Compliance includes RoHS, UL Listed, and CSA Certification, which supports energy safety standards and regulatory audits. This combination delivers reliable protection for multi-phase control circuits while enabling straightforward maintenance and fuse replacement in demanding industrial environments.
Yes. The HM60030-3SR is specifically designed for three-pole protection using Class H and Class K fuse types. This compatibility supports flexible protection schemes and helps maintain consistent performance across the Eaton Bussmann HM family. By using the designated class fuses, you preserve protection ratings, simplify sourcing, and ensure predictable operation in motor control and automation applications.
Regulatory audits rely on RoHS compliance, UL Listed status, and CSA Certification for the HM60030-3SR. These certifications validate material restrictions, electrical safety, and conformity to applicable standards. Including these attestations in procurement and engineering documentation reduces supplier qualification time and supports compliance across global manufacturing operations.
The modular three-pole HM60030-3SR simplifies maintenance by enabling rapid fuse replacement and clear phase isolation, which cuts downtime during fault events. Its compact size reduces panel redesign needs and frees up space for additional components. Over the device lifecycle, the combination of UL Listed, CSA Certified, and RoHS compliance lowers compliance risk, while straightforward sourcing of Class H and Class K fuses minimizes spare part inventories and procurement effort, delivering measurable uptime improvements.
