Eaton HM60100-2CR Fuse Block - UL Listed 10 kAIC
Part Number: HM60100-2CR
Quick Summary
The Eaton HM60100-2CR fuse block provides modular overcurrent protection for electrical panels and equipment. For engineers upgrading legacy panels or expanding critical circuits, the unit offers fast, plug‑and‑play protection that fits tight spaces and minimizes wiring complexity. It carries UL Listed and CSA Certified markings and RoHS compliance, with Class K and Class H ratings to support selective coordination and long-term reliability. The two‑pole CR design supports compact installation in motor control centers, distribution boards, and industrial control panels, reducing spare parts and service time. By combining robust protection with easy maintenance, this module helps ensure uptime while meeting stringent safety and environmental requirements.
Product Information
Extended Description
HM60100-2CR Eaton: Eaton Bussmann series HM modular fuse block, CR, 70-100 A, Two-pole, Class K, Class H, 10 kAIC, 600 V
Product Name
Eaton Bussmann series HM modular fuse block
Catalog Number
HM60100-2CR
UPC
051712391160
Product Length/Depth
8 in
Product Height
2.5 in
Product Width
3 in
Product Weight
0.103 lb
Warranty
Not Applicable
Compliances
RoHS Compliant
Certifications
Contact Manufacturer UL Listed CSA Certified
Amperage Rating
70-100A
Short-circuit rating
10 kA
Voltage rating
600 V
Number of Poles
Two-pole
Class
Class K Class H
Special features
CR
Bussmann series complete full line catalog no. 1007
Bussmann series complete full line catalog no. 1007
Bussmann series Fuseology
Bussmann series Fuseology
Eaton Specification Sheet - HM60100-2CR
Feature → Business Impact → Application: The modular two-pole design enables efficient use of panel real estate and simplifies future upgrades, reducing installation time and labor costs in new builds or retrofits. This translates to measurable downtime reduction and lower maintenance expense for industrial facilities, especially in tight control panels or retrofit projects. Feature → Business Impact → Application: Electrical ratings of 70–100 A, 600 V and 10 kAIC provide robust protection for demanding loads, enabling reliable selective coordination and minimizing nuisance tripping in motor drives and distribution sections. This is critical for manufacturing lines and HVAC systems where uptime drives productivity and energy efficiency. Feature → Business Impact → Application: Class K and Class H compatibility supports selective fusing, improving fault isolation and safety in control panels and MCCs. Ideal for heavy industry, process automation, and energy-intensive applications. Feature → Business Impact → Application: RoHS compliant, UL Listed, CSA Certified certifications ensure regulatory compliance and safety, reducing audit findings and supplier risk across global operations. Feature → Business Impact → Application: CR feature and Bussmann HM lineage deliver easy cross-reference, fast part replacement, and consistent performance across shared infrastructure in control panels, distribution boards, and machine automation cabinets.
Get a Quick Quote for a Eaton HM60100-2CR
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton HM60100-2CR?
Enquire Now
FAQs
The HM60100-2CR is a two-pole modular fuse block designed for industrial protection in panels, motor control centers and distribution boards. It fits standard Bussmann HM configurations and supports Class K and Class H fusing, enabling selective coordination in compact spaces without sacrificing safety or reliability.
The unit is rated for 70–100 A with a short-circuit rating of 10 kA at 600 V. This combination supports demanding industrial loads, reduces nuisance trips, and enhances selective coordination in power distribution and motor circuits.
Yes. The HM60100-2CR carries UL Listed and CSA Certified markings and is RoHS compliant, ensuring regulatory compliance for electrical protection devices across North American manufacturing and installation environments.
Installation benefits include a compact 8 in length, 3 in width, and 2.5 in height footprint with a lightweight 0.103 lb mass, enabling quick mounting in tight panels. The CR feature simplifies maintenance and replacement, reducing downtime and stocking needs for spare parts in ongoing operations.
Typical applications include protection in motor control centers, distribution panels, and industrial control cabinets across manufacturing, energy, HVAC, and process industries. Its two-pole design, high short-circuit rating, and RoHS/UL CSA certifications make it suitable for centralized panel protection with regulatory compliance.
