Eaton HM60200-2CR Modular Fuse Block - 10 kAIC
Part Number: HM60200-2CR
Quick Summary
Eaton HM60200-2CR modular fuse block protects electrical circuits in power distribution and machine control panels. This compact two-pole device helps engineers balance high current protection with fast fault clearance, reducing downtime and component wear. With RoHS compliance, UL Listed, and CSA Certified, it aligns with global safety and environmental standards. The HM60200-2CR combines Class H and Class K protection and a CR feature for flexible fuse management, delivering reliable protection in modern automation environments while supporting streamlined maintenance and cost-effective asset management. This design simplifies field servicing by using widely compatible Bussmann series components and an intuitive two-pole fuse arrangement. Industrial buyers benefit from predictable protection curves, easy integration with control circuits, and a robust 600 V rating in demanding environments.
Product Information
Extended Description
HM60200-2CR Eaton: Eaton Bussmann series HM modular fuse block, CR, 110-200 A, Two-pole, Class H, Class K, 10 kAIC, 600 V
Product Name
Eaton Bussmann series HM modular fuse block
Catalog Number
HM60200-2CR
UPC
051712387309
Product Length/Depth
0.001 in
Product Height
0.001 in
Product Width
0.001 in
Product Weight
0.1 lb
Warranty
Not Applicable
Compliances
RoHS Compliant
Certifications
Contact Manufacturer UL Listed CSA Certified
Amperage Rating
110-200A
Short-circuit rating
10 kA
Voltage rating
600 V
Number of Poles
Two-pole
Class
Class K Class H
Special features
CR
HM60200-2CR~200 amp class H fuse holder 600V - 2 pol
HM60200-2CR~200 amp class H fuse holder 600V - 2 pol
Class H(K), J and R Power distribution fuse block overview
Class H(K), J and R Power distribution fuse block overview
Eaton Specification Sheet - HM60200-2CR
Amperage range and voltage rating enable flexible protection for demanding loads. The HM60200-2CR covers 110-200 A at up to 600 V, with a 10 kA short-circuit rating, delivering fast fault clearance and reduced arc energy. This combination supports MCCs and high-current feeders in automation environments, minimizing downtime while preserving equipment life. The modular design simplifies stocking and replacements within maintenance programs since Bussmann HM components are widely used. Class H and Class K protection options offer selective coordination for motor feeders and power distribution. Designers can balance protection sensitivity with nuisance-trip reduction, improving reliability during starts and transients. Applications span power distribution panels, machine centers, and process equipment in heavy industry, with easy integration into existing control schemes and clear documentation trails for audits. CR feature within the HM family adds flexible fuse mounting and management, enabling streamlined field upgrades without major rewiring. This translates to faster maintenance windows, reduced labor costs, and standardized spares across multiple lines, valuable in multi-plant operations. The device’s compatibility with the Bussmann series also supports scalable protection architectures as facilities expand. Reliability and compliance are reinforced by RoHS, UL Listed, and CSA Certified status. This ensures regulatory acceptance in North America and many global markets, supporting safe integration with equipment from different manufacturers and meeting environmental standards. The high current rating and sturdy construction also help sustain uptime in harsh industrial environments. Installation and compatibility are enhanced by the HM Bussmann modular ecosystem. The two-pole configuration and 600 V rating simplify wiring in control panels, MCCs, and switchgear, while standardized footprints reduce engineering time. Clear labeling, durable housings, and consistent accessory availability further accelerate project timelines and support long-term asset reliability.
Get a Quick Quote for a Eaton HM60200-2CR
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton HM60200-2CR?
Enquire Now
FAQs
Install the HM60200-2CR in a control panel by mounting the two-pole unit within the HM modular fuse block footprint and wiring each pole to the protected circuits. Ensure the panel is de-energized before work, follow the 110–200 A and 600 V ratings, and use proper terminals and safety practices. Verify UL Listed and RoHS labeling after installation.
The HM60200-2CR is rated for 110-200 A with a 10 kA short-circuit rating at 600 V. It is a two-pole device supporting Class H and Class K fuses, RoHS compliant, and UL Listed with CSA Certified. Use these ratings to determine protection coordination in your feeders.
Yes. The HM60200-2CR is designed for 600 V systems and is commonly used in motor control centers, switchgear, and power distribution panels. Its two-pole configuration and dual-class protection support selective coordination, while a 10 kAIC rating helps meet MCC fault levels. Always coordinate with motor protection devices and verify compatibility with your MCC design.
The HM60200-2CR is RoHS compliant, UL Listed, and CSA Certified, reflecting safety and environmental standards for North American and international deployments. These certifications facilitate regulatory approvals, supplier audits, and installation acceptance in critical facilities. Ensure proper documentation is kept for compliance and warranty purposes.
The modular design simplifies spare parts management and field servicing, enabling quick fuse replacement with minimal panel downtime. The HM60200-2CR supports scalable protection schemes across lines, reducing inventory diversity. With UL/CSA RoHS compliance and consistent performance, facilities realize lower maintenance costs and improved uptime over asset lifecycles.
