Eaton IZMX-AS22-40-1 PXR Auxiliary Switch - UL Listed
Part Number: IZMX-AS22-40-1
Quick Summary
Eaton IZMX-AS22-40-1 is an auxiliary switch used with NRX frames to enhance control in motor protection circuits. Designers often wrestle with wiring complexity and delayed fault signaling when expanding protection schemes. This UL Listed PXR Auxiliary Switch simplifies wiring, speeds diagnostics, and handily integrates with RF frames and the Long Leads Kit. By consolidating signaling paths and providing a dedicated contact, it reduces panel wiring time and improves safety in UL-compliant panels. The device is compact, dependable, and ready for scalable control architectures, delivering consistent performance in harsh industrial environments while supporting reliable maintenance and future expansion.
Product Information
Extended Description
IZMX-AS22-40-1 Eaton: Eaton Power Defense ICCB auxiliary switch, PXR Auxiliary Switch, Long Leads Kit, Power Defense ICCB, RF Frame, PXR
Product Name
Eaton Series NRX auxiliary switch
Catalog Number
IZMX-AS22-40-1
UPC
786685998510
Product Length/Depth
8 in
Product Height
2 in
Product Width
2 in
Product Weight
1.5 lb
Certifications
UL Listed
Type
PXR Auxiliary Switch
Special features
Long Leads Kit
Trip Type
T253
Frame
RF
Accessories
Auxiliary switch
Series
Series NRX
Compatibility with NRX frames and RF frame installations enables seamless integration within Power Defense ICCB configurations, reducing integration risk and enabling faster commissioning. The PXR auxiliary switch brings a dedicated signaling path that improves fault indication and diagnostics, boosting operational uptime and reducing mean time to repair. UL Listed certification provides confidence in safety compliance and panel-level reliability, helping meet stringent industry standards without additional certification costs. The Long Leads Kit option enhances remote signaling capabilities, simplifying field wiring and enabling cleaner cable management in complex switchgear architectures. With a compact footprint (8 in x 2 in x 2 in) and a weight of 1.5 lb, installation fits neatly into crowded control cabinets, supporting scalable, modular expansion. This device aligns with NRX series accessories for consistent performance across Eaton protection solutions, delivering measurable efficiency gains and predictable maintenance cycles for industrial environments.
