Eaton IZMX-UVR48DC-1 Undervoltage Release - UL Listed
Part Number: IZMX-UVR48DC-1
Quick Summary
The Eaton IZMX-UVR48DC-1 undervoltage release protects motor circuits by monitoring 24-48 Vdc and triggering the release when undervoltage is detected. This helps prevent unexpected restarts and equipment damage in motor control centers. UL Listed certification confirms safety compliance for industrial environments, while its universal NRX frame compatibility ensures easy retrofits across multiple starter configurations. The unit is designed as a 48 Vdc UVR Assy Kit – PXR, matching the Power Defense ICCB line to streamline installation. With compact dimensions and a standard 8.75 in depth, it integrates into existing panels with minimal wiring changes, delivering reliability, reduced maintenance, and improved uptime for critical processes.
Product Information
Extended Description
IZMX-UVR48DC-1 Eaton: Eaton Power Defense ICCB undervoltage release, 48 Vdc UVR Assy Kit – PXR, Power Defense ICCB, Universal, 24-48 Vdc, PXR
Product Name
Eaton Series NRX undervoltage release
Catalog Number
IZMX-UVR48DC-1
UPC
786685997780
Product Length/Depth
8.75 in
Product Height
2 in
Product Width
4 in
Product Weight
1.75 lb
Certifications
UL Listed
Type
48 Vdc UVR Assy Kit – PXR
Voltage rating
24-48 Vdc
Trip Type
T253
Frame
Universal
Accessories
Undervoltage release
Series
Series NRX
Voltage range and UVR kit integration drive compatibility across common DC control circuits, enabling seamless retrofits with minimal wiring changes. Business impact: reduced installation time and fewer field errors while improving protection accuracy. Application: fits NRX contactor assemblies and Power Defense ICCB systems in conveyors, packaging lines, and machine centers. Trip type T253 provides a defined release threshold, delivering predictable shutdowns during undervoltage events. Business impact: minimizes nuisance trips and protects loads and drives, reducing unplanned downtime. Application: ideal for critical automation sequences in manufacturing and packaging. Universal NRX frame compatibility simplifies stock management and spare parts strategy, enabling quicker service across multiple line configurations. Business impact: lowers maintenance costs and accelerates commissioning. Application: retrofit-friendly for existing control panels. Installation advantages include the PXR UVR kit integration for faster field swaps and safer, compliant operation. Business impact: improves safety margins and supports regulatory adherence. The UL Listed certification reinforces safety for industrial environments, while compact dimensions and standard mounting in a universal frame support scalable deployment. Application: suited to diverse panel layouts and enclosures, delivering proven reliability.
Get a Quick Quote for a Eaton IZMX-UVR48DC-1
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton IZMX-UVR48DC-1?
Enquire Now
FAQs
IZMX-UVR48DC-1 is designed for universal NRX frames and pairs with the PXR UVR kit to simplify retrofits. The result is straightforward mounting, reduced wiring changes, and faster deployment in existing motor control panels, minimizing downtime during upgrades.
The unit operates on a 24-48 Vdc input with a T253 trip type, delivering a controlled undervoltage release. This combination yields predictable protection behavior, helping to prevent unintended energization and load damage in DC control circuits.
Yes, IZMX-UVR48DC-1 is UL Listed, validating safety for industrial environments. It is intended for use with Power Defense ICCB systems and NRX starters, enabling safe, compliant operation in a wide range of industrial applications.
It uses a Universal frame within the Series NRX family and ships as part of the 48 Vdc UVR Assy Kit – PXR. The kit approach streamlines integration with Power Defense ICCB configurations and NRX contactor assemblies.
Expected ROI comes from reduced nuisance trips, shorter maintenance windows, and improved uptime for critical processes. The compact footprint and universal frame minimize panel changes, while UL safety certification supports compliance across manufacturing environments.
