Eaton JBXPC0G07MSNDSMR JBX push-pull connector - IP40/IP68
Part Number: JBXPC0G07MSNDSMR
Quick Summary
The Eaton Souriau JBX push-pull connector provides rugged, reliable interconnection for industrial automation and control panels. Engineers often contend with vibration, moisture ingress, and space constraints in demanding environments; this compact, metallic interconnect helps mitigate those challenges. With UL 1977 compliance and IP40/IP68 sealing, it offers robust safety and environmental protection, while the straight backshell and sealing gland with optional boot simplify field installation. The design supports efficient panel layouts and accelerated assembly, delivering measurable business value through reduced downtime and streamlined maintenance. For teams pursuing dependable, compliant connectivity in harsh settings, this solution pairs strong protection with ease of integration and lifecycle cost benefits.
Product Information
Extended Description
JBXPC0G07MSNDSMR Eaton: In line cable receptacle, IP40, size 0, 7 male contacts, cable clamp protective boot; JBXPC0G07MSNDSMR
Product Name
Eaton Souriau JBX series IP40 / IP68 metallic push-pull connector
Catalog Number
JBXPC0G07MSNDSMR
Product Length/Depth
38 mm
Product Height
10 mm
Product Width
10 mm
Product Weight
11.75 g
Compliances
UL 1977
Backshell angle
Straight
Backshell type
Sealing Gland With Optional Boot
Feature: IP40/IP68 metallic push-pull connector with 7 male contacts supports in-line cable receptacle assembly. Business Impact: Provides durable, dust- and moisture-protected connectivity suitable for demanding factory floors and outdoor installations, reducing fault rates and maintenance downtime. Application: Industrial control panels and automation cabinets requiring reliable seals and quick mating. Feature: Backshell type with sealing gland and optional boot enhances environmental sealing. Business Impact: Minimizes ingress paths for dust, water, and contaminants, extending component life in harsh settings. Application: Conveyor systems and heavy equipment exposed to temperature and moisture fluctuations. Feature: Compact form factor with 38 mm length and 10x10 mm footprint reduces panel footprint. Business Impact: Increases control-panel density and enables more flexible layout planning, lowering enclosure costs. Application: Space-constrained electrical enclosures and compact robotics interfaces. Feature: UL 1977 compliance ensures recognized safety and performance standards. Business Impact: Improves regulatory confidence and simplifies supplier qualification processes for safety-critical environments. Application: Alloyed automation networks and modular control architectures requiring certified connectors. Feature: 11.75 g weight contributes to lighter assemblies and easier handling. Business Impact: Reduces installation fatigue and supports dynamic machinery where weight matters, improving overall system reliability. Application: Mobile equipment and automated lines where weight balance affects performance. Feature: Straight backshell and 7-contact configuration enable straightforward mating and reliable electrical performance. Business Impact: Shortens assembly time, lowers training needs for technicians, and reduces risk of misalignment. Application: Retrofit projects and new machine builds in metalworking, packaging, and material handling.
Get a Quick Quote for a Eaton JBXPC0G07MSNDSMR
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton JBXPC0G07MSNDSMR?
Enquire Now
FAQs
To install, align the JBXPC0G07MSNDSMR with its mating receptacle, then engage the push-pull mechanism until a secure lock is felt. Use the cable clamp protective boot to provide strain relief and protect the conductors from flexing and vibration. The unit is an in-line cable receptacle with a straight backshell designed to complement Souriau JBX series components for straightforward integration into standard control panels.
This connector features 7 male contacts in a compact inline receptacle with IP40/IP68 protection and a straight backshell. It complies with UL 1977, weighing 11.75 g and measuring 38 mm in depth with a 10 x 10 mm cross-section footprint. These specs support reliable operation in harsh industrial environments and provide a robust, seals-classified interface for control systems.
The IP40/IP68 rating offers versatile protection against dust and moisture, making it suitable for many outdoor and washdown-adjacent applications where ingress control is critical. For environments requiring higher immersion or extensive jet wash exposure, confirm the specific IP68 rating and installation conditions to ensure sustained performance in your exact process.
The connector is UL 1977 compliant, which supports safety and performance expectations in industrial interconnection components. This certification helps with regulatory alignment, supplier qualification, and risk mitigation for automation systems deployed in regulated or safety-conscious facilities.
The push-pull mating design reduces cycle time and operator effort during field assembly and maintenance, lowering labor costs and downtime. Its sealed, robust construction minimizes ingress-related failures, extending service intervals and reducing replacement frequency. Overall, the JBXPC0G07MSNDSMR contributes to a favorable total cost of ownership by improving reliability and maintenance efficiency.
