Eaton JDL200 Fuse - Time-delay, 600 V, 200 kAIC
Part Number: JDL200
Quick Summary
The Eaton JDL200 fuse is a time-delay current-limiting device designed for reliable protection in electrical distribution panels. Engineers face startup surges that can trigger nuisance trips, so this fuse balances surge tolerance with fast fault interruption to protect equipment and maintain uptime. It is CE marked and RoHS compliant, reflecting global regulatory readiness for diverse installations, while its 200 kAIC interrupt rating provides strong fault clearance. By pairing robust protection with standard Edison-series compatibility and convenient packaging, this solution supports efficient procurement and streamlined project execution, offering both reliability and business value for industrial power systems.
Product Information
Extended Description
JDL200 Eaton: Eaton Edison series JDL fuse, Time-delay current-limiting fuse, Non-indicating, 200 A, Dual, J, Non-indicating, 200 kAIC, 5, 600 V
Product Name
Eaton Edison series JDL fuse
Catalog Number
JDL200
UPC
782634803546
Product Length/Depth
5.75 in
Product Height
1.63 in
Product Width
1.63 in
Product Weight
4.25 lb
Warranty
Not Applicable
Compliances
CE Marked RoHS Compliant
Amperage Rating
200 A
Interrupt rating
200 kAIC
Voltage rating
600 V
Number of elements
Dual
Packaging type
Standard
Class
Class J
Fuse indicator
Non-indicating
Quantity
5
Special features
Non-indicating
Feature → Time-delay current-limiting design reduces nuisance trips during startup while preserving fast fault interruption. Impact → Minimizes unplanned downtime and extends equipment life by avoiding repetitive cycling. Application → Ideal for motor feeders and control panels where startup surges are common. Feature → 200 A rating with 200 kAIC interrupt rating at 600 V. Impact → Provides robust protection for high-current feeders and short-circuit events, reducing conductor damage and service interruptions. Application → Suitable for industrial machines, power distribution panels, and heavy-duty feeders. Feature → Class J fuse design with dual elements in a standard 5-pack simplifies panel design and stocking. Impact → Ensures predictable response characteristics across circuits and reduces maintenance checks. Application → Works with Edison-series fuse blocks in control panels and machine interfaces. Feature → Compliance with CE Mark and RoHS standards. Impact → Speeds time-to-market and reduces qualification effort on global deployments. Application → Ideal for international OEM builds and installations in markets with regulatory requirements. Feature → Compatibility and installation efficiency with Edison-series packaging and standard dimensions. Impact → Saves installation time and reduces risk of misfit; supports rapid replacement during maintenance. Application → Suitable for service teams and OEMs integrating into new builds.
