Eaton JGHDC3150FAW PVGard Solar MCCB - UL 489
Part Number: JGHDC3150FAW
Quick Summary
Eaton PVGard Solar MCCB provides reliable overcurrent protection for solar PV installations. Engineers often confront DC/AC coordination challenges, nuisance trips, and difficult field terminations that delay deployment. This device carries UL 489 certification and is compatible with CE-marked markets, supporting regional safety and compliance. With a 150 A rating and 600 Vac / 250 Vdc capability, it fits PV system protection needs while simplifying procurement and maintenance for the broader Eaton MCCB family. The result is a safer, more efficient protection scheme for renewable energy projects and industrial DC distribution.
Product Information
Extended Description
JGHDC3150FAW Eaton: Eaton Series G DC/PvGard complete molded case circuit breaker, JG-frame, JG, Complete breaker, Fixed thermal, adjustable magnetic trip type, Three-pole, 150A, 600 Vac, 250 Vdc, Without terminals, Vdc
Product Name
Eaton PV Guard / Solar complete molded case circuit breaker
Catalog Number
JGHDC3150FAW
UPC
786685494517
Product Length/Depth
3.57 in
Product Height
4.13 in
Product Width
4.13 in
Product Weight
6.5 lb
Warranty
Eaton Selling Policy 25-000, one (1) year from the date of installation of the Product or eighteen (18) months from the date of shipment of the Product, whichever occurs first.
Certifications
UL 489
Amperage Rating
150 A
Voltage rating
600 Vac, 250 Vdc
Trip Type
T185
Circuit breaker type
JG
Circuit breaker frame type
Complete breaker
Terminals
Without terminals
Frame
JG
Class
Vdc
Number of poles
Three-pole
PVGard solar circuit breakers product aid
Circuit Protection, Molded Case Circuit Breakers, Volume 4, Tab 2
Value of Circuit Breakers for PV Systems and Eaton PVGard Solar Circuit Breakers
Eaton Specification Sheet - JGHDC3150FAW
Eaton Specification Sheet - JGHDC3150FAW
Feature → Business Impact → Application: The JG frame, three-pole design delivers reliable protection for DC PV and AC circuits in compact spaces, reducing downtime and improving panel density in rooftop and ground-mounted PV installations. This translates to lower installation costs and easier future expansion in solar plants. Application: PV systems requiring robust overcurrent protection with precise trip coordination. Feature → Business Impact → Application: 150 A rating paired with T185 trip type provides fast, adjustable protection against short-circuits, minimizing damage to inverters and wiring while enabling safe maintenance windows. Application: Commercial and industrial solar facilities needing dependable fault isolation. Feature → Business Impact → Application: Without terminals configuration simplifies field wiring and reduces terminal block complexity, improving install speed and minimizing field termination errors. Application: Renovations or upgrades of legacy MCCB panels in solar portfolios. Feature → Business Impact → Application: UL 489 certification and JG frame compatibility deliver standards-based protection with easy integration into existing MCCB ecosystems, reducing procurement risk. Application: New builds or retrofits seeking vendor-consistent parts. Feature → Business Impact → Application: 4.13 in width/height and 3.57 in depth with a 6.5 lb weight support space planning and mounting efficiency in compact enclosures. Application: Rooftop cabinets and compact electrical rooms in PV deployments.
