Eaton JGHDC3225FAG Molded Case Circuit Breaker - UL 489
Part Number: JGHDC3225FAG
Quick Summary
Eaton JGHDC3225FAG PV Guard molded case circuit breaker protects solar PV systems from overloads and faults, enabling safe, reliable power delivery in industrial and commercial installations. In busy electrical rooms, engineers and technicians often struggle with protection devices that are compact, easy to install, and deliver predictable tripping behavior. UL 489 certification ensures safe operation, and the three-pole, 225 A design supports robust PV protection while enabling straightforward integration with PVGuard configurations. Designed for PV applications, this complete breaker combines fixed thermal with adjustable magnetic trip, a durable copper-wired construction, and metric mounting hardware to streamline panel design. Together with Eaton PVGuard products, it delivers reliable protection, reduced downtime, and clear maintenance pathways for solar projects.
Product Information
Extended Description
JGHDC3225FAG Eaton: Series G JG-frame molded case circuit breaker, 225A, Three-pole, With terminals, Fixed thermal, adjustable magnetic, Cu wire, With collars, JGHDC type
Product Name
Eaton PV Guard / Solar complete molded case circuit breaker
Catalog Number
JGHDC3225FAG
UPC
786685494470
Product Length/Depth
3.57 in
Product Height
4.13 in
Product Width
4.13 in
Product Weight
6.5 lb
Warranty
Eaton Selling Policy 25-000, one (1) year from the date of installation of the Product or eighteen (18) months from the date of shipment of the Product, whichever occurs first.
Certifications
UL 489
Amperage Rating
225 A
Voltage rating
600 Vac, 250 Vdc
Trip Type
T185
Circuit breaker type
JG
Circuit breaker frame type
Complete breaker
Terminals
Line and load
Frame
JG
Class
Vdc
Mounting hardware
Metric
Number of poles
Three-pole
PVGard solar circuit breakers product aid
Circuit Protection, Molded Case Circuit Breakers, Volume 4, Tab 2
Value of Circuit Breakers for PV Systems and Eaton PVGard Solar Circuit Breakers
Eaton Specification Sheet - JGHDC3225FAG
Eaton Specification Sheet - JGHDC3225FAG
Feature: Three-pole, complete JG-frame breaker rated at 225 A with line and load terminals. Business Impact: Centralizes protection for PV inverters and feeders, reducing fault propagation and simplifying panel design. Application: Suits PVGuard deployments in commercial and utility-scale solar installations. Feature: Fixed thermal, adjustable magnetic (trip type T185). Business Impact: Delivers coordinated, precise fault isolation and minimizes nuisance trips, improving system uptime. Application: Protective coordination with upstream protections in PV arrays and DC-AC interfaces. Feature: Compact dimensions and weight (3.57 in depth, 4.13 in height, 4.13 in width; 6.5 lb). Business Impact: Enhances panel density and simplifies replacement in crowded control enclosures. Application: Retrofit or new builds where space is constrained. Feature: Terminals for line and load with metric mounting hardware. Business Impact: Optimizes wiring reliability and reduces installation time through standardized mounting and secure connections. Application: Mounting in OEM panels and service equipment used for solar protection. Feature: UL 489 certified, compatible with PVGuard solar protection schemes. Business Impact: Provides proven compliance with electrical protection standards, easing commissioning and maintenance. Application: Solar microgrid, rooftop, and utility-scale protection schemes.
