Eaton JGS3150FAG Molded Case Circuit Breaker - UL Listed
Part Number: JGS3150FAG
Quick Summary
Eaton Series G molded case circuit breaker protects industrial power systems in panels and feeders. Engineers often struggle to find a device that fits tight spaces, meets stringent safety standards, and provides reliable protection across varying voltages. This unit carries UL Listed, CSA Certified, IEC Rated, and CE Marking, offering world-class compliance and easier sourcing for global projects. The 150 A rating, 600 Vac capability, and three-pole JG frame deliver scalable protection for motor loads and power distribution. With fixed thermal trip and adjustable magnetic trip, it balances nuisance tripping and selective coordination, while compact form factors and metric mounting simplify installation and service, delivering lower lifecycle costs and less downtime.
Product Information
Extended Description
JGS3150FAG Eaton: Eaton Series G molded case circuit breaker, JG-frame, JG, Fixed thermal, adjustable magnetic trip, Three-pole, 150 A, 600 Vac, 85 kAIC at 240 Vac, 35 kAIC at 480 Vac, 18 kAIC at 600 Vac, Line and load, Metric, 50/60 Hz, 80% rated
Product Name
Eaton Series G complete molded case circuit breaker
Catalog Number
JGS3150FAG
UPC
782113526782
Product Length/Depth
3.57 in
Product Height
4.13 in
Product Width
4.13 in
Product Weight
6 lb
Warranty
Eaton Selling Policy 25-000, one (1) year from the date of installation of the Product or eighteen (18) months from the date of shipment of the Product, whichever occurs first.
Compliances
CE Marked
Certifications
UL Listed CSA Certified IEC Rated
Type
Complete breaker
Amperage Rating
150 A
Voltage rating
600 Vac
Trip Type
T185
Circuit breaker type
JG
Circuit breaker frame type
Complete breaker
Rating
80% rated
Series
Series G
Terminals
Line and load
Frame
JG
Frequency rating
50/60 Hz
Mounting hardware
Metric
Interrupt rating
18 kAIC at 600 Vac 35 kAIC at 480 Vac 85 kAIC at 240 Vac
Number of poles
Three-pole
Application of Tap Rules to Molded Case Breaker Terminals
Application of Tap Rules to Molded Case Breaker Terminals
High performance operating handles for Series G circuit breakers product aid
High performance operating handles for Series G circuit breakers product aid
High performance operating handles for Series G circuit breakers product aid
High performance operating handles for Series G circuit breakers product aid
High performance operating handles for Series G circuit breakers product aid
High performance operating handles for Series G circuit breakers product aid
High performance operating handles for Series G circuit breakers product aid
High performance operating handles for Series G circuit breakers product aid
High performance operating handles for Series G circuit breakers product aid
High performance operating handles for Series G circuit breakers product aid
High performance operating handles for Series G circuit breakers product aid
High performance operating handles for Series G circuit breakers product aid
Breaker service centers
Circuit Protection, Molded Case Circuit Breakers, Volume 4, Tab 2
Eaton Specification Sheet - JGS3150FAG
Eaton Specification Sheet - JGS3150FAG
Eaton Specification Sheet - JGS3150FAG
Selling Policy 25-000 - Distribution and Control Products and Services
Three-pole JG frame with 150 A rating and line/load terminals enables precise, dependable overcurrent protection. The business impact is improved protection density and simplified panel design, reducing space requirements and installation time. This is especially applicable to industrial control panels and motor feeders in manufacturing environments. Fixed thermal and adjustable magnetic trip (T185) delivers stable protection while enabling selective coordination with downstream devices. The business impact is minimised nuisance trips and enhanced safety compliance across variable loads, making it ideal for pumps, conveyors, and fans in process industries. Interrupt ratings across voltages provide resilience against short circuits, reducing risk of arc flash and equipment damage and enabling safe, fast disconnections. This is critical in distribution panels and machine rooms within harsh industrial settings. Metric mounting hardware and a compact footprint ease installation and retrofit in existing panels, saving installation time and labor costs. The Eaton compatibility ecosystem supports quick accessory integration, improving serviceability in constrained spaces common to control panels and switchgear. Compliance and warranty support procurement confidence and long-term reliability, with UL Listed, CSA Certified, IEC Rated, and CE Marked status plus a one-year warranty (or 18 months from shipment). This combination reduces regulatory risk and supports global project execution and maintenance planning.
Get a Quick Quote for a Eaton JGS3150FAG
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton JGS3150FAG?
Enquire Now
FAQs
Yes. The JGS3150FAG uses metric mounting hardware designed for fast, straightforward installation in standard industrial panels. Its line and load terminals support straightforward wiring, and the compact 3.57 in x 4.13 in x 4.13 in footprint helps retrofit existing enclosures without requiring major panel redesigns. For best results, pair with Eaton Series G accessories intended for JG frame breakers.
The device features a fixed thermal trip with an adjustable magnetic (T185) trip, delivering reliable protection while allowing coordination with downstream devices. It provides 18 kAIC interrupt rating at 600 Vac, ensuring rapid disconnection of fault currents in typical industrial power networks. This combination supports safe motor control and line protection against short circuits.
Absolutely. With a 150 A rating, 600 Vac capacity, and three-pole design, the JGS3150FAG is well-suited for motor feeders and panel protection in manufacturing and processing facilities. Its Series G architecture and robust interrupt ratings help maintain motor start reliability while minimizing downtime, even in environments with frequent transients and surges.
This breaker is UL Listed, CSA Certified, IEC Rated, and CE Marked, ensuring broad regulatory compliance for global projects. These certifications support import/export, cross-border procurement, and adherence to safety codes, reducing vendor diversity requirements and simplifying qualification testing for control panels and switchgear assemblies.
Series G MCCBs offer high reliability with a defined warranty period and broad certifications, which lowers maintenance surprises and replacement cycle uncertainty. The unit’s compact footprint, ease of installation, and compatibility with Eaton service centers help reduce labor costs, minimize downtime, and extend service life in manufacturing environments.
