Eaton JGS3150FAGA1 Molded Case Breaker - UL Listed 150A 600V
Part Number: JGS3150FAGA1
Quick Summary
The Eaton JGS3150FAGA1 molded-case breaker provides reliable overload protection for industrial electrical panels. In fast-moving facilities, incorrect protection leads to nuisance trips, downtime, and escalated maintenance costs. This unit carries UL Listed certification, and is designed for 50/60 Hz systems with a 600 Vac rating. Built around the Series G, it supports robust, scalable protection in demanding environments, while offering easy integration with existing panel architectures and plug-in adapters for enhanced configurability.
Product Information
Extended Description
JGS3150FAGA1 Eaton: Eaton Series G molded case circuit breaker, JG-frame, JG, Fixed thermal, adjustable magnetic trip, Three-pole, 150A, 600 Vac, 85 kAIC at 240 Vac, 35 kAIC at 480 Vac, 18 kAIC at 600 Vac, Line and load, 1A-1B w/ right pigtail, 50/60 Hz
Product Name
Eaton Series G complete molded case circuit breaker
Catalog Number
JGS3150FAGA1
UPC
786685888323
Product Length/Depth
9.25 in
Product Height
5 in
Product Width
5 in
Product Weight
6 lb
Warranty
Eaton Selling Policy 25-000, one (1) year from the date of installation of the Product or eighteen (18) months from the date of shipment of the Product, whichever occurs first.
Compliances
Contact Manufacturer
Certifications
UL Listed
Type
Fixed adjustable
Amperage Rating
150 A
Voltage rating
600 Vac
Trip Type
T185
Circuit breaker type
JG
Circuit breaker frame type
Complete breaker
Auxiliary switch
1A-1B with right pigtail
Series
Series G
Terminals
Line and load
Frame
JG
Frequency rating
50/60 Hz
Interrupt rating
35 kAIC at 480 Vac 85 kAIC at 240 Vac 18 kAIC at 600 Vac
Number of poles
Three-pole
