Eaton JGS316032W Molded Case Circuit Breaker - 85kAIC@240V
Part Number: JGS316032W
Quick Summary
The Eaton JGS316032W molded case circuit breaker protects electrical feeders in industrial switchgear and panelboards. It helps prevent nuisance trips and unplanned downtime by delivering precise trip characteristics and robust overload protection. This unit carries CE Marked, CSA Certified, UL Listed, and IEC Rated certifications, supporting safe, global installations. With a compact three-pole design and metric mounting, it integrates easily into existing panels while delivering reliable performance and lifecycle cost savings.
Product Information
Extended Description
JGS316032W Eaton: Eaton Series G, JG-frame Molded Case Circuit Breaker, Complete breaker , 160A, 85 kAIC at 240V, 40 kAIC at 415V, 35 kAIC at 480V, 18 kAIC at 600V, Three-pole, 600V, Metric, Line and load, 310+ electronic LSI
Product Name
Eaton Series G molded case circuit breaker
Catalog Number
JGS316032W
UPC
786689025434
Product Length/Depth
3.57 in
Product Height
7 in
Product Width
4.13 in
Product Weight
6 lb
Warranty
Eaton Selling Policy 25-000, one (1) year from the date of installation of the Product or eighteen (18) months from the date of shipment of the Product, whichever occurs first.
Compliances
CE Marked
Certifications
CSA Certified UL Listed IEC Rated
Type
Complete breaker
Amperage Rating
160 A
Voltage rating
600 V
Trip Type
T40
Frame size
JG-frame
Terminals
Line and load
Mounting hardware
Metric
Interrupt rating
35 kAIC at 480 Vac 40 kAIC at 415 Vac 85 kAIC at 240 Vac 18 kAIC at 600 Vac
Number of poles
Three-pole
Three-pole, 160 A capacity with line and load terminals provides solid protection for three-phase feeders while simplifying wiring and panel integration, reducing installation time and potential wiring errors. The T40 trip type enables selective protection and faster fault clearance, protecting critical motors and drives while limiting collateral damage and downtime. With voltage ratings up to 600 V and interrupt ratings of 85 kAIC at 240 V, 40 kAIC at 415 V, 35 kAIC at 480 V, and 18 kAIC at 600 V, this MCCB sustains high fault currents without compromising safety, ensuring reliability in demanding manufacturing lines. Metric mounting hardware and the JG-frame design enable straightforward retrofits into standard panel envelopes, supporting quick upgrades and reduced commissioning costs. Compliance with CE, UL, and CSA standards helps procurement teams meet global regulatory requirements while maintaining consistent performance across sites.
