Eaton JGS316032W Molded Case Circuit Breaker - 85kAIC@240V
Part Number: JGS3160AAG
Quick Summary
The Eaton JGS316032W molded case circuit breaker protects electrical feeders in industrial switchgear and panelboards. It helps prevent nuisance trips and unplanned downtime by delivering precise trip characteristics and robust overload protection. This unit carries CE Marked, CSA Certified, UL Listed, and IEC Rated certifications, supporting safe, global installations. With a compact three-pole design and metric mounting, it integrates easily into existing panels while delivering reliable performance and lifecycle cost savings.
Product Information
Extended Description
JGS3160AAG Eaton: Eaton Series G molded case circuit breaker, JG-frame, JG, Adjustable thermal, adjustable magnetic trip, Three-pole, 160A, 600 Vac, 85 kAIC at 240 Vac, 35 kAIC at 480 Vac, 18 kAIC at 600 Vac, Line and load, Metric, Not UL rated, 50/60 Hz
Product Name
Eaton Series G complete molded case circuit breaker
Catalog Number
JGS3160AAG
UPC
782114886274
Product Length/Depth
3.57 in
Product Height
4.13 in
Product Width
4.13 in
Product Weight
6 lb
Warranty
Eaton Selling Policy 25-000, one (1) year from the date of installation of the Product or eighteen (18) months from the date of shipment of the Product, whichever occurs first.
Compliances
CE Marked
Certifications
UL Listed CSA Certified IEC Rated
Type
Complete breaker
Special features
Not UL rated
Amperage Rating
160 A
Voltage rating
600 Vac
Trip Type
Adjustable thermal, adjustable magnetic
Circuit breaker type
JG
Circuit breaker frame type
Complete breaker
Series
Series G
Terminals
Line and load
Frame
JG
Frequency rating
50/60 Hz
Mounting hardware
Metric
Interrupt rating
18 kAIC at 600 Vac 35 kAIC at 480 Vac 85 kAIC at 240 Vac
Number of poles
Three-pole
Application of Multi-Wire Terminals for Molded Case Circuit Breakers
Application of Multi-Wire Terminals for Molded Case Circuit Breakers
High performance operating handles for Series G circuit breakers product aid
High performance operating handles for Series G circuit breakers product aid
High performance operating handles for Series G circuit breakers product aid
High performance operating handles for Series G circuit breakers product aid
High performance operating handles for Series G circuit breakers product aid
High performance operating handles for Series G circuit breakers product aid
High performance operating handles for Series G circuit breakers product aid
High performance operating handles for Series G circuit breakers product aid
High performance operating handles for Series G circuit breakers product aid
High performance operating handles for Series G circuit breakers product aid
High performance operating handles for Series G circuit breakers product aid
High performance operating handles for Series G circuit breakers product aid
Breaker service centers
Circuit Protection, Molded Case Circuit Breakers, Volume 4, Tab 2
Eaton Specification Sheet - JGS3160AAG
Eaton Specification Sheet - JGS3160AAG
Eaton Specification Sheet - JGS3160AAG
Three-pole, 160 A capacity with line and load terminals provides solid protection for three-phase feeders while simplifying wiring and panel integration, reducing installation time and potential wiring errors. The T40 trip type enables selective protection and faster fault clearance, protecting critical motors and drives while limiting collateral damage and downtime. With voltage ratings up to 600 V and interrupt ratings of 85 kAIC at 240 V, 40 kAIC at 415 V, 35 kAIC at 480 V, and 18 kAIC at 600 V, this MCCB sustains high fault currents without compromising safety, ensuring reliability in demanding manufacturing lines. Metric mounting hardware and the JG-frame design enable straightforward retrofits into standard panel envelopes, supporting quick upgrades and reduced commissioning costs. Compliance with CE, UL, and CSA standards helps procurement teams meet global regulatory requirements while maintaining consistent performance across sites.
Get a Quick Quote for a Eaton JGS3160AAG
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton JGS3160AAG?
Enquire Now
FAQs
The JGS316032W uses metric mounting hardware designed for standard panel enclosures. Its JG-frame, three-pole configuration and line/load terminals simplify installation and retrofit projects, enabling quick integration into existing MCCBs and switchgear without extensive panel modification.
The device provides 85 kAIC at 240 V, 40 kAIC at 415 V, 35 kAIC at 480 V, and 18 kAIC at 600 V. This range ensures reliable fault current interruption across typical industrial power networks, supporting both low- and high-voltage applications.
Yes. The unit is CE Marked, UL Listed, CSA Certified, and IEC Rated, aligning with international safety and performance standards. This certification suite supports cross-border procurement and helps ensure regulatory compliance in diverse facilities.
Ideal for three-phase motor circuits, panelboards, and switchgear in manufacturing plants, the JGS316032W provides reliable overload protection, quick fault clearance, and easy system upgrades due to its compact JG-frame design and line/load terminals.
Eaton offers a warranty under policy 25-000, valid for one year from installation or eighteen months from shipment, whichever occurs first. This covering supports post-installation service, replacements, and ensuring long-term performance consistency.
