Eaton JGS3200FAG Complete MCCB - UL Listed
Part Number: JGS3200FAG
Quick Summary
Eaton Series G complete molded case circuit breaker provides reliable protection for industrial electrical panels. In demanding control environments, improper protection can lead to nuisance trips and unplanned downtime, impacting productivity and maintenance costs. This unit is UL Listed, CSA Certified, and CE Marked, with IEC-rated performance to support global deployments and cross-border compliance. The JG frame, three-pole design, and metric mounting hardware deliver a compact yet robust protection solution. With a 200 A rating at 600 V, it enables scalable panel architectures while simplifying installation and service, ultimately reducing total cost of ownership for industrial automation and power distribution applications.
Product Information
Extended Description
JGS3200FAG Eaton: Eaton Series G complete molded case circuit breaker, JG Frame, 200 A, Three-pole, 600V, 85 kAIC at 240V, 40 kAIC at 415V, 35 kAIC at 480V, 18 kAIC at 600V, Line/load standard w/ metric mounting hardware, Fixed thermal, adj. magnetic
Product Name
Eaton Series G complete molded case circuit breaker
Catalog Number
JGS3200FAG
UPC
782113526799
Product Length/Depth
3.57 in
Product Height
4.13 in
Product Width
4.13 in
Product Weight
6 lb
Warranty
Eaton Selling Policy 25-000, one (1) year from the date of installation of the Product or eighteen (18) months from the date of shipment of the Product, whichever occurs first.
Compliances
CE Marked
Certifications
CSA Certified IEC Rated UL Listed
Type
Complete breaker
Amperage Rating
200 A
Voltage rating
600 Vac
Trip Type
T185
Circuit breaker type
JG
Circuit breaker frame type
Complete breaker
Terminals
Line and load
Frame
JG
Mounting hardware
Metric
Interrupt rating
18 kAIC at 600 Vac 40 kAIC at 415 Vac 85 kAIC at 240 Vac 35 kAIC at 480 Vac
Number of poles
Three-pole
