Eaton JGS3200FAGC Complete MCCB - 600 Vac CE UL Listed
Part Number: JGS3200FAGC
Quick Summary
Eaton JGS3200FAGC is a complete molded case circuit breaker for protecting three-phase power circuits in industrial automation. In demanding panel environments, under- or over-sizing MCCBs leads to nuisance trips, downtime, and costly rewiring. This JG-frame MCCB combines fixed thermal with an adjustable magnetic trip (T185) to deliver reliable, precise protection for critical loads. It carries IEC rated, UL Listed, and CSA Certified approvals with CE marking, supporting global compliance and streamlined supplier qualification. For panel builders and end users, the compact three-pole assembly fits space-constrained enclosures while copper line/load terminals and metric mounting hardware simplify installation and reduce commissioning torque variability. This translates to faster startup and lower lifecycle costs for control systems.
Product Information
Extended Description
JGS3200FAGC Eaton: Eaton Series G molded case circuit breaker, JG-frame, JG, Fixed thermal, adj. magnetic trip, Three-pole, 200A, 600 Vac, 85 kAIC at 240 Vac, 40 kAIC at 415 Vac, 35 kAIC at 480 Vac, 18 kAIC at 600 Vac, Copper, Line/load, Metric, 100% rated
Product Name
Eaton Series G complete molded case circuit breaker
Catalog Number
JGS3200FAGC
UPC
786685290942
Product Length/Depth
3.57 in
Product Height
4.13 in
Product Width
4.13 in
Product Weight
6 lb
Warranty
Eaton Selling Policy 25-000, one (1) year from the date of installation of the Product or eighteen (18) months from the date of shipment of the Product, whichever occurs first.
Compliances
CE Marked
Certifications
IEC Rated UL Listed CSA Certified
Type
Complete breaker
Amperage Rating
200 A
Voltage rating
600 Vac
Trip Type
T185
Circuit breaker type
JG
Circuit breaker frame type
Complete breaker
Rating
100% rated
Terminals
Line and load
Frame
JG
Mounting hardware
Metric
Terminal material
Copper
Interrupt rating
18 kAIC at 600 Vac 40 kAIC at 415 Vac 35 kAIC at 480 Vac 85 kAIC at 240 Vac
Number of poles
Three-pole
