Eaton JGS3225FAGA1 MCCB - 225A, 600V, T185 Trip

The 225 A amperage rating provides robust overload protection for demanding line and load profiles, reducing the risk of nuisance trips in high-current applications and improving process stability. This translates to fewer unscheduled outages and lower maintenance overhead, especially in MCC environments where motor loads and feeder conductors demand dependable protection. The 600 Vac voltage rating expands compatibility with medium- and high-voltage distribution schemes, enabling a single MCCB family to cover multiple sections of a control panel without sacrificing protection accuracy. With a fixed adjustable trip (T185) and three-pole JG frame, engineers gain precise coordination and predictable fault clearance, improving selectivity across adjacent protection devices and simplifying panel design. The auxiliary switch (1A-1B rear with 48 in right pigtail) provides remote status indication for maintenance windows and control logic, reducing diagnostic time during startups and fault analysis. The three-pole configuration and line/load terminals establish clear, safe installation paths for wiring, supporting straightforward field wiring and serviceability. The interrupt ratings—85 kAIC at 240 Vac, 40 kAIC at 415 Vac, 35 kAIC at 480 Vac, and 18 kAIC at 600 Vac—offer robust fault handling across diverse supply conditions, enabling protection of motors, drives, and lighting feeders with confidence. Integrated Series G architecture gives installers compatibility with common control panels and plug-in accessories, streamlining retrofits and future expansions. From a lifecycle perspective, the JGS3225FAGA1 helps shorten commissioning time, reduce downtime, and lower total cost of ownership through dependable performance and widely available replacement parts.
