Eaton JGX3100AAG Molded Case Circuit Breaker - 200 kAIC
Part Number: JGX3100AAG
Quick Summary
The Eaton JGX3100AAG Molded Case Circuit Breaker provides reliable overcurrent protection for industrial power distribution and control panels. It helps prevent nuisance trips while safeguarding equipment and personnel in demanding environments. This three-pole, 100 A unit from the Series G line combines adjustable thermal and magnetic trip to support selective coordination with upstream devices. It carries recognized certifications including UL Listed, CSA Certified, IEC Rated, and CE Marked, ensuring global compliance across diverse projects from North America to Europe. With line-and-load terminals and a compact JG frame, it installs quickly in panelboards and control cabinets, while its 50/60 Hz operation and 80% rated setting optimize performance in real-world industrial applications. This translates to reduced downtime and easier OEM integration.
Product Information
Extended Description
JGX3100AAG Eaton: Eaton Series G molded case circuit breaker, JG-frame, JG, Adjustable thermal, adjustable magnetic trip, Three-pole, 100A, 600 Vac, 250 Vdc, 200 kAIC at 240 Vac, 200 kAIC at 480 Vac, 50 kAIC at 600 Vac, Line and load, 50/60 Hz, 80% rated
Product Name
Eaton Series G complete molded case circuit breaker
Catalog Number
JGX3100AAG
UPC
786685126869
Product Length/Depth
3.44 in
Product Height
7 in
Product Width
4.13 in
Product Weight
6 lb
Warranty
Eaton Selling Policy 25-000, one (1) year from the date of installation of the Product or eighteen (18) months from the date of shipment of the Product, whichever occurs first.
Compliances
CE Marked
Certifications
IEC Rated UL Listed CSA Certified
Type
Complete breaker
Amperage Rating
100 A
Voltage rating
600 Vac, 250 Vdc
Trip Type
Adjustable thermal, adjustable magnetic
Circuit breaker type
JG
Circuit breaker frame type
Complete breaker
Rating
80% rated
Series
Series G
Terminals
Line and load
Frame
JG
Frequency rating
50/60 Hz
Interrupt rating
200 kAIC at 480 Vac 50 kAIC at 600 Vac 200 kAIC at 240 Vac
Number of poles
Three-pole
