Eaton JGX3125AAG Complete MCCB - UL Listed, 200 kAIC
Part Number: JGX3125AAG
Quick Summary
Eaton JGX3125AAG Complete MCCB provides reliable overcurrent protection for motor control centers. Too often, assemblies suffer nuisance trips or poor selectivity when trip settings aren’t aligned to load profiles. This unit is UL Listed, CSA Certified, and IEC Rated, ensuring regulatory compliance and dependable protection across global panels. With adjustable thermal and magnetic trip, it adapts to 125 A at 600 Vac and supports 50/60 Hz systems, reducing downtime and extending equipment life. Built on the Series G molded case platform, it streamlines installation in panel boards with line and load terminals and metric mounting hardware, delivering safer operation and long-term cost savings for OEMs and plant engineers.
Product Information
Extended Description
JGX3125AAG Eaton: Eaton Series G molded case circuit breaker, JG-frame, JG, Adjustable thermal, adjustable magnetic trip, Three-pole, 125A, 600 Vac, 200 kAIC at 240 Vac, 200 kAIC at 480 Vac, 50 kAIC at 600 Vac, Line and load, Metric, 50/60 Hz, 80% rated
Product Name
Eaton Series G complete molded case circuit breaker
Catalog Number
JGX3125AAG
UPC
786685126876
Product Length/Depth
3.57 in
Product Height
4.13 in
Product Width
4.13 in
Product Weight
6 lb
Warranty
Eaton Selling Policy 25-000, one (1) year from the date of installation of the Product or eighteen (18) months from the date of shipment of the Product, whichever occurs first.
Compliances
CE Marked
Certifications
UL Listed CSA Certified IEC Rated
Type
Complete breaker
Amperage Rating
125 A
Voltage rating
600 Vac
Trip Type
Adjustable thermal, adjustable magnetic
Circuit breaker type
JG
Circuit breaker frame type
Complete breaker
Rating
80% rated
Series
Series G
Terminals
Line and load
Frame
JG
Frequency rating
50/60 Hz
Mounting hardware
Metric
Interrupt rating
200 kAIC at 480 Vac 50 kAIC at 600 Vac 200 kAIC at 240 Vac
Number of poles
Three-pole
