Eaton JHL1 Fuse - 600 V Class J, UL Listed
Part Number: JHL1
Quick Summary
The Eaton JHL1 fuse provides high-speed overcurrent protection for power electronics and motor drives in industrial automation. Engineers frequently encounter nuisance trips and downtime during rapid load changes; the JHL1 addresses this with precise high-speed protection. It carries CE marking, RoHS compliance, and UL listing (with CSA certification) to meet global safety and regulatory demands. Designed for use with power semiconductor devices, this non-indicating fuse supports reliable protection in control panels and drives, helping reduce repair costs and improve uptime.
Product Information
Extended Description
JHL1 Eaton: Eaton Edison JHL high speed fuse, 600V, 1A, 200 kAIC, Non Indicating, Melamine tube with silver fuse element
Product Name
Eaton Edison series JHL fuse
Catalog Number
JHL1
UPC
782634107002
Product Length/Depth
0.001 in
Product Height
0.001 in
Product Width
0.001 in
Product Weight
0.001 lb
Warranty
No warranty
Compliances
CE Marked RoHS Compliant
Certifications
CSA Certified UL Listed
Amperage Rating
1 A
Interrupt rating
200 kAIC
Voltage rating
600 V
Material
Melamine tube with silver fuse element
Packaging type
Standard
Fuse indicator
Non Indicating
Quantity
10
Used with
Power semiconductor devices
JHL1~Edison High Speed Class J Fuse
JHL1~Edison High Speed Class J Fuse
Bussmann series Fuseology
Eaton Specification Sheet - JHL1
Feature 600 V operating voltage with 1 A rating and a 200 kAIC interrupt capacity ensures rapid fault clearance. Business Impact This combination minimizes damage to power electronics and reduces unplanned downtime in drives and inverters. Application It is particularly well-suited for motor drives, UPS stages, and other power semiconductor devices in industrial controls. Feature Non-indicating design simplifies panel layout and reduces visual clutter; external signaling can be used for fault monitoring. Business Impact This improves installation efficiency in dense panels and enables flexible status reporting. Application Works well with LED indicators managed upstream, enabling clean, scalable protection schemes. Feature Melamine tube with silver fuse element offers reliable performance under industrial conditions. Business Impact This provides consistent operation and predictable response across temperature and vibration. Application Ideal for harsh environments in manufacturing and processing. Feature Certifications and compliance include CE, RoHS, UL Listed, and CSA certification. Business Impact This ensures regulatory alignment and simplifies procurement across regions. Application Stocking and compatibility are enhanced with standard packaging of ten fuses per pack, supporting maintenance workflows.
Get a Quick Quote for a Eaton JHL1
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton JHL1?
Enquire Now
FAQs
To install the JHL1, ensure the system is de-energized, align the fuse with the holder terminals, insert fully, and secure the clip. Verify compatibility with 200 kAIC interrupt rating and do not force-fit; confirm the application is within 600 V limits and follow manufacturer torque specifications if applicable.
Key specs include 1 A amperage rating, 600 V voltage rating, 200 kAIC interrupt rating, non-indicating status, melamine tube with a silver fuse element, and standard packaging of ten fuses per unit.
Yes. The JHL1 is designed for fast fault clearing in power semiconductor devices found in motor drives and industrial controls, helping to limit damage from short circuits and reduce downtime.
The JHL1 is CE marked, RoHS compliant, UL Listed, and CSA Certified, supporting global safety and regulatory compliance for European and North American deployments.
Using the JHL1 improves uptime through rapid fault interruption, simplifies procurement with ten-fuse packs, and provides regulatory confidence with recognized certifications, making maintenance and stocking more predictable in industrial automation environments.
