Eaton JHL100 Edison Fuse - 200 kAIC UL Listed
Part Number: JHL100
Quick Summary
Eaton Edison JHL fuse provides high-speed overcurrent protection for power electronics in motor drives. Many engineers face nuisance trips and downtime from slower protection in demanding loads. This fuse meets RoHS, CE, UL Listed, and CSA Certified standards, providing regulatory confidence for panel builders. Designed for 600 Vac and 450 Vdc systems, 100 A with 200 kAIC, this non-indicating device protects expensive semiconductors while remaining readily sourced in standard 5-pack configurations. Customers value the Edison lineup for panel space efficiency, consistent performance, and easy stocking for field service. With a focus on power electronics protection, this fuse helps engineer teams meet safety and reliability targets while controlling total cost of ownership.
Product Information
Extended Description
JHL100 Eaton: Eaton Edison JHL high speed fuse, 600 Vac, 450 Vdc, 100A, 200 kAIC, Non Indicating, Melamine tube with silver fuse element
Product Name
Eaton Edison series JHL fuse
Catalog Number
JHL100
UPC
782634107026
Product Length/Depth
0.001 in
Product Height
0.001 in
Product Width
0.001 in
Product Weight
0.001 lb
Warranty
No warranty
Compliances
RoHS Compliant CE Marked
Certifications
CSA Certified UL Listed
Amperage Rating
100 A
Interrupt rating
200 kAIC
Voltage rating
600 Vac, 450 Vdc
Material
Melamine tube with silver fuse element
Packaging type
Standard
Fuse indicator
Non Indicating
Quantity
5
Used with
Power semiconductor devices
JHL100~Edison High Speed Class J Fuse
JHL100~Edison High Speed Class J Fuse
Bussmann series Fuseology
Eaton Specification Sheet - JHL100
Feature: High-speed protection with a 200 kAIC interrupt rating and Class J construction provides rapid fault clearance in high-energy industrial circuits. Business impact: fast interruption minimizes arc energy, protects sensitive power semiconductors, and reduces downtime during fault events, saving maintenance costs and preserving equipment integrity. Application: ideal for motor drives, inverters, and power supplies in factory automation, where fast response times directly translate to higher line availability and safer panel performance. Feature: 600 Vac / 450 Vdc voltage ratings and a 100 A current rating offer ample headroom for startup surges and transient events. Business impact: designers can rely on a single protective device across mixed AC and DC sections, simplifying BOMs and lowering stocking complexity. Application: protection of DC bus paths, AC input stages, and high-current power electronics in automated machines. Feature: Non-indicating fuse in a melamine tube with a silver fuse element yields a compact, rugged, and cost-effective solution with consistent performance. Business impact: reduced panel clutter and easier field replacements; standardized 5-pack packaging improves procurement efficiency and reduces downtime waiting for replacements. Application: service stock for control panels and OEM assemblies across industrial sites. Feature: RoHS compliant, CE marked, UL Listed, and CSA Certified. Business impact: these certifications streamline compliance processes for panel builds, export, and installations in multiple regions, lowering risk and accelerating time-to-production. Application: global deployments of automation equipment, switchgear assemblies, and machine controls in regulated environments. Feature: Compatibility with Eaton Edison series and standard Class J fuse holders; standard packaging type simplifies installation. Business impact: faster installs, fewer compatibility issues, and improved spare-part management for maintenance teams. Application: panel builders, OEM integrators, and field service teams working with power semiconductor devices.
Get a Quick Quote for a Eaton JHL100
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton JHL100?
Enquire Now
FAQs
The JHL100 is intended for use with standard Edison Class J fuse holders found in most industrial panels. Ensure the circuit voltage does not exceed 600 Vac or 450 Vdc and the current rating is within the system’s fault current limits. Install in clean, vibration-free enclosures and follow Eaton's installation guidelines to maintain electrical clearance, terminal torque, and safe replacement procedures.
Key specifications include 600 Vac, 450 Vdc, 100 A, and 200 kAIC, with non-indicating operation and a melamine tube with a silver fuse element. The device is RoHS compliant, CE marked, UL Listed, and CSA Certified, and ships in a standard 5-pack. These specs support reliable protection for power electronics in industrial automation and ensure regulatory alignment for global installations.
Yes. JHL100 is designed to protect power semiconductor devices used in motor drives, inverters, and DC link protection within automation systems. It provides fast interruption for both AC and DC applications at the rated voltage and current, reducing the risk of device damage during fault conditions. For DC applications, ensure the DC voltage remains within 450 Vdc and verify correct enclosure cooling.
JHL100 carries RoHS compliance, CE marking, UL Listed, and CSA Certified. These certifications demonstrate environmental responsibility, safety compliance, and compatibility with regulatory requirements across regions. For panel builders and OEMs, this simplifies procurement, reduces compliance risk, and accelerates acceptance in EU and North American markets.
Using JHL100 can reduce downtime during fault events thanks to its high interrupt rating and fast isolation of faults in high-energy loads. The non-indicating design and 5-pack packaging support easier stocking and service readiness, lowering total cost of ownership. While it lacks a visual fault indicator, periodic panel checks ensure reliable protection and longer equipment life.
