Eaton JHL110 Edison High Speed Fuse - UL Listed
Part Number: JHL110
Quick Summary
Eaton JHL110 Edison high-speed fuse provides fast overcurrent protection for power semiconductor devices. Engineers in motor drives and power electronics struggle with nuisance trips and unreliable protection in rapid switching environments. It carries UL Listed and CSA Certified marks and is CE Marked RoHS compliant, ensuring regulatory alignment for global deployments. For panel builders and OEMs, it simplifies compliance and reduces downtime, delivering robust Class J fast-acting protection. Its non-indicating design and standard packaging support easy stocking and straightforward replacement in industrial controls.
Product Information
Extended Description
JHL110 Eaton: Eaton Edison JHL high speed fuse, 600 Vac, 450 Vdc, 110A, 200 kAIC, Non Indicating, Melamine tube with silver fuse element
Product Name
Eaton Edison series JHL fuse
Catalog Number
JHL110
UPC
782634107033
Product Length/Depth
0.001 in
Product Height
0.001 in
Product Width
0.001 in
Product Weight
0.001 lb
Warranty
No warranty
Compliances
CE Marked RoHS Compliant
Certifications
CSA Certified UL Listed
Amperage Rating
110 A
Interrupt rating
200 kAIC
Voltage rating
600 Vac, 450 Vdc
Material
Melamine tube with silver fuse element
Packaging type
Standard
Fuse indicator
Non Indicating
Quantity
5
Used with
Power semiconductor devices
JHL110~Edison High Speed Class J Fuse
JHL110~Edison High Speed Class J Fuse
Bussmann series Fuseology
Eaton Specification Sheet - JHL110
The JHL110 offers a 200 kAIC interrupt rating at 600 Vac and 450 Vdc, enabling fast fault clearance in high-energy systems. This translates to shorter arc exposure, reduced damage to power electronics, and lower maintenance costs for drives and inverters. In practice, installers can rely on its Class J fast-acting performance to protect sensitive power semiconductors without nuisance tripping during startup transients. With an amperage rating of 110 A and a non-indicating design, it provides robust protection while keeping panel LEDs simple and cost-effective. The melamine tube with a silver fuse element delivers consistent performance in typical industrial environments, offering reliable operation under heat and vibration commonly seen in manufacturing floors. Packaging is standard and commonly supplied in five-unit quantities, simplifying stocking and replacement planning for OEMs and contractors. Compliance is reinforced by UL Listed, CSA Certified, and CE RoHS marks, enabling straightforward regulatory acceptance across regional markets. Installation compatibility is ensured with Eaton’s Edison JHL family, designed for high-speed protection of power semiconductor devices in drives, inverters, and other control applications. This combination of features supports faster deployment, reduced downtime, and lower total cost of ownership in industrial automation projects.
