Eaton JHL12 Edison fuse - UL Listed, 600V, 12A, 200 kAIC
Part Number: JHL12
Quick Summary
Eaton JHL12 Edison fuse protects power semiconductors by delivering high-speed overcurrent protection for drive circuits. Engineers often struggle with nuisance trips and slow commissioning when protection devices lag behind fast-switching loads. This fuse is RoHS compliant and CE marked, UL listed, and CSA certified, ensuring regulatory alignment across North America and Europe. Designed for power semiconductor devices in industrial drives, it delivers reliable performance in harsh factory environments. The combination of precise ratings and durable construction supports predictable maintenance schedules, easier sourcing, and lower total cost of ownership. In practice, teams report fewer unplanned outages and shorter mean time to repair when using certified protection like JHL12.
Product Information
Extended Description
JHL12 Eaton: Eaton Edison JHL high speed fuse, 600V, 12A, 200 kAIC, Non Indicating, Melamine tube with silver fuse element
Product Name
Eaton Edison series JHL fuse
Catalog Number
JHL12
UPC
782634107040
Product Length/Depth
0.001 in
Product Height
0.001 in
Product Width
0.001 in
Product Weight
0.001 lb
Warranty
No warranty
Compliances
RoHS Compliant CE Marked
Certifications
UL Listed CSA Certified
Amperage Rating
12 A
Interrupt rating
200 kAIC
Voltage rating
600 V
Material
Melamine tube with silver fuse element
Packaging type
Standard
Fuse indicator
Non Indicating
Quantity
10
Used with
Power semiconductor devices
Bussmann series complete full line catalog no. 1007
Bussmann series complete full line catalog no. 1007
Bussmann series Fuseology
Eaton Specification Sheet - JHL12
The JHL12 delivers high-speed protection for power semiconductors, which reduces the time a fault can affect downstream components and drives. This translates to lower damage costs, shorter downtime, and improved equipment longevity in automated production lines. Its 600 V, 12 A rating with a 200 kAIC interrupt capability ensures robust performance in modern drive topologies, including motor drives and rectifier modules. The non-indicating design keeps assemblies simple and cost-effective, while relying on system diagnostics for fault location, minimizing maintenance complexity. Built with a melamine tube and silver fuse element, the device withstands industrial heat cycles and delivers consistent performance in harsh environments. Compliance with RoHS, CE, UL, and CSA reduces regulatory risk across global facilities. Packaging and procurement benefits include standard packaging and convenient quantity per order, aiding spare-part planning for electrical protection and circuit-control programs. This functional combination addresses common objections about protection accuracy and lifecycle cost by offering clear, measurable reliability and straightforward installation.
Get a Quick Quote for a Eaton JHL12
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton JHL12?
Enquire Now
FAQs
JHL12 is designed for standard high-speed fuse holders that support 12 A, 600 V devices. Confirm holder compatibility using the Eaton datasheet and ensure the panel is wired for non-indicating protection to support reliable fault isolation in power semiconductor applications.
The JHL12 is rated for 600 V with a 12 A continuous current rating and an interrupt rating of 200 kAIC, suitable for protecting power semiconductor devices in demanding drive and rectifier applications.
Yes. The JHL12 is specifically designed for power semiconductor devices in industrial drives, motor control centers, and drive electronics, delivering fast clearing to minimize damage and downtime in drive systems.
JHL12 carries UL Listed and CSA Certified marks, and is RoHS compliant with CE marking. These certifications support regulatory compliance across North America and Europe for electrical protection components.
By providing rapid fault isolation, reducing downstream damage, and simplifying spare-parts management, JHL12 lowers maintenance costs, shortens downtime, and improves panel-design reliability for electrical protection and circuit-control programs.
