Eaton JHL3 Fuse - Edison Class J UL Listed 200kAIC
Part Number: JHL3
Quick Summary
The Eaton Edison JHL3 fuse protects power semiconductor devices with high-speed response for industrial drives and motor controls. When faults occur, downtime and damaged electronics hit production schedules hard; dependable protection is essential. The device carries UL Listed, CSA Certified, and CE RoHS compliance for global acceptability. With a 600 V rating, 3 A amperage, and a 200 kAIC interrupt rating, it provides fast fault isolation without nuisance trips. Designed for straightforward replacement within Eaton’s Edison line, it supports efficient maintenance, streamlined procurement, and consistent performance across sites.
Product Information
Extended Description
JHL3 Eaton: Eaton Edison JHL high speed fuse, 600V, 3A, 200 kAIC, Non Indicating, Melamine tube with silver fuse element
Product Name
Eaton Edison series JHL fuse
Catalog Number
JHL3
UPC
782634107163
Product Length/Depth
0.001 in
Product Height
0.001 in
Product Width
0.001 in
Product Weight
0.001 lb
Warranty
No warranty
Compliances
CE Marked RoHS Compliant
Certifications
UL Listed CSA Certified
Amperage Rating
3 A
Interrupt rating
200 kAIC
Voltage rating
600 V
Material
Melamine tube with silver fuse element
Packaging type
Standard
Fuse indicator
Non Indicating
Quantity
10
Used with
Power semiconductor devices
JHL3~Edison High Speed Class J Fuse
JHL3~Edison High Speed Class J Fuse
Bussmann series Fuseology
Eaton Specification Sheet - JHL3
