Eaton JHL30 Fuse Edison Series - UL Listed 200 kAIC
Part Number: JHL30
Quick Summary
Eaton JHL30 fuse is a high-speed protective device designed for 600 V power circuits and power semiconductor drives. In fast switching applications, selecting a fuse with insufficient interrupt capability or wrong rating can lead to nuisance trips or inadequate protection for critical components. This model meets UL Listed, CSA Certified, and CE Marked RoHS standards, reinforcing safety and regulatory compliance across diverse markets. The JHL30 combines reliability with practical installation advantages, including standard packaging and a non-indicating design that reduces panel clutter. With a 30 A rating and a 200 kAIC interrupt capacity, it provides robust fault isolation for drives and inverter stages while optimizing total cost of ownership for you.
Product Information
Extended Description
JHL30 Eaton: Eaton Edison JHL high speed fuse, 600V, 30A, 200 kAIC, Non Indicating, Melamine tube with silver fuse element
Product Name
Eaton Edison series JHL fuse
Catalog Number
JHL30
UPC
782634107170
Product Length/Depth
0.001 in
Product Height
0.001 in
Product Width
0.001 in
Product Weight
0.001 lb
Warranty
No warranty
Compliances
CE Marked RoHS Compliant
Certifications
UL Listed CSA Certified
Amperage Rating
30 A
Interrupt rating
200 kAIC
Voltage rating
600 V
Material
Melamine tube with silver fuse element
Packaging type
Standard
Fuse indicator
Non Indicating
Quantity
10
Used with
Power semiconductor devices
Bussmann series complete full line catalog no. 1007
Bussmann series complete full line catalog no. 1007
Bussmann series Fuseology
Eaton Specification Sheet - JHL30
600 V protection with a 30 A rating and a 200 kAIC interrupt capacity delivers rapid fault isolation for high-energy drives. The business impact is reduced equipment damage and minimized downtime when protective devices respond to faults in milliseconds. This makes the JHL30 ideal for power semiconductor devices in inverters and motor controllers, where fast clearing is essential and nuisance trips are unacceptable. Melamine tube with a silver fuse element delivers robust electrical performance with stable fusing characteristics, supporting reliable protection in demanding environments. Non-indicating design minimizes panel clutter and simplifies maintenance, while compatibility with standard fuse holders enables straightforward retrofits in existing control panels. UL Listed, CSA Certified, and CE RoHS compliance ensure audit-ready regulatory adherence and supplier confidence. Packaged in a standard 10-per-package format, the JHL30 helps streamline procurement and spare parts planning, reducing inventory costs and lead times across multiple sites.
Get a Quick Quote for a Eaton JHL30
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton JHL30?
Enquire Now
FAQs
Choose a compatible fuse holder and wiring that matches the 30 A rating. Remember that the JHL30 is non-indicating, so rely on system status indicators or the Eaton specification sheet to confirm operational status. Use standard panel layouts and ensure secure mounting to withstand vibration in industrial environments.
The JHL30 is rated for 600 V and 30 A with an interruption rating of 200 kAIC. It uses a melamine tube with a silver fuse element, is non-indicating, and is designed for power semiconductor protection, providing fast fault clearing in drive and inverter applications.
Yes. With 600 V operation, 30 A rating, and a 200 kAIC interrupt capacity, the JHL30 is well-suited for protecting inverter stages and motor drive circuits, where rapid fault isolation minimizes device damage and unplanned downtime.
The JHL30 carries UL Listed, CSA Certified, and CE Marked RoHS compliance, ensuring safety, regulatory alignment, and reduced risk during audits across North America and Europe.
The JHL30 is packaged in standard units with a quantity of 10 per package. It carries no warranty, per the product data, and is designed for straightforward procurement and consistent stock in manufacturing environments.
