Eaton JHL35 Edison fuse - UL Listed
Part Number: JHL35
Quick Summary
Eaton Edison JHL fuse provides fast-acting overcurrent protection for power semiconductor devices in industrial drives. This helps prevent nuisance trips that disrupt startup sequences and erode uptime. The design carries UL Listed, CSA Certified, and CE RoHS compliance, reinforcing reliability across regional installations. With a 600 Vac / 450 Vdc rating, 35 A amperage, and 200 kAIC interrupt capability, it protects power electronics while supporting compact panel designs. For engineers and procurement teams, the non-indicating fuse reduces maintenance checks, and the standard packaging of ten fuses simplifies stocking and replacements during outages. This combination delivers predictable protection, regulatory assurance, and total cost of ownership benefits for modern automation projects.
Product Information
Extended Description
JHL35 Eaton: Eaton Edison JHL high speed fuse, 600 Vac, 450 Vdc, 35A, 200 kAIC, Non Indicating, Melamine tube with silver fuse element
Product Name
Eaton Edison series JHL fuse
Catalog Number
JHL35
UPC
782634107194
Product Length/Depth
0.001 in
Product Height
0.001 in
Product Width
0.001 in
Product Weight
0.001 lb
Warranty
No warranty
Compliances
CE Marked RoHS Compliant
Certifications
CSA Certified UL Listed
Amperage Rating
35 A
Interrupt rating
200 kAIC
Voltage rating
600 Vac, 450 Vdc
Material
Melamine tube with silver fuse element
Packaging type
Standard
Fuse indicator
Non Indicating
Quantity
10
Used with
Power semiconductor devices
Bussmann series complete full line catalog no. 1007
Bussmann series complete full line catalog no. 1007
Bussmann series Fuseology
Eaton Specification Sheet - JHL35
Feature 1: High interrupt rating of 200 kAIC at 600 Vac / 450 Vdc. Business Impact: Provides robust fault-clearing capability that minimizes damage to power electronics and downstream loads. Application: Ideal for power semiconductor devices in industrial drive systems where high-energy transients occur. Feature 2: 35 A amperage with a 600 Vac / 450 Vdc rating. Business Impact: Delivers reliable overcurrent protection while enabling compact, efficient panel layouts. Application: Protection for motor drives and DC link circuits in automation equipment. Feature 3: Non-indicating design. Business Impact: Reduces panel clutter and simplifies replacement workflows by removing visual status indicators. Application: Field replacements and OEM panel assembly in automation cabinets. Feature 4: Melamine tube with silver fuse element. Business Impact: Ensures fast, predictable fuse operations with stable performance in high-temperature environments. Application: Industrial protection where rapid interruption is critical for uptime. Feature 5: Compliance and certifications (UL Listed, CSA Certified, CE RoHS). Business Impact: Supports regulatory qualification and supplier approval, easing procurement across regions. Application: Global manufacturing environments requiring formal conformity. Feature 6: Standard packaging (Quantity 10). Business Impact: Streamlines stocking, reduces downtime, and improves logistics efficiency. Application: Service and maintenance cycles in large-scale automation projects.
Get a Quick Quote for a Eaton JHL35
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton JHL35?
Enquire Now
FAQs
When integrating the JHL35 into a motor drive panel, ensure adequate clearance for heat dissipation from the melamine tube and verify mounting compatibility with standard fuse holders. Use proper cable sizing for 35 A circuits and confirm that the panel wiring aligns with the 600 Vac / 450 Vdc rating. Consider spare fuse inventory to minimize downtime during replacements.
The JHL35 fuse provides a 35 A amperage rating, voltage rating of 600 Vac and 450 Vdc, and a high interrupt rating of 200 kAIC. It is designed for non-indicating operation and uses a melamine tube with a silver fuse element, suitable for protection of power semiconductor devices in automation systems.
The JHL35 is a non-indicating fuse, meaning it does not provide a visual blown-fuse indicator in the panel. This reduces panel clutter and simplifies replacement workflows, though it requires alternate state monitoring (electrical continuity tests or device-side diagnostics) to confirm fuse status during maintenance.
The JHL35 carries UL Listed and CSA Certified marks and CE RoHS compliance. These certifications support regulatory acceptance, supplier qualification, and market access across North America and Europe, reducing procurement risk for OEMs and service providers in regulated industries.
Using the JHL35 can lower maintenance costs by reducing nuisance trips and enabling quick replacements due to standard packaging (ten per pack). The high 200 kAIC interrupt rating provides robust protection for power electronics, potentially lowering unplanned downtime and extending component life in motor drives and power semiconductor applications.
