Eaton JHL45 Fuse - Edison High-Speed 200 kAIC CE RoHS
Part Number: JHL45
Quick Summary
Eaton JHL45 fuse delivers fast overcurrent protection for power electronics in industrial automation. Engineers often wrestle with nuisance trips and downtime from surges that threaten equipment and uptime; this high-speed fuse helps minimize damage while keeping systems online. It is CE marked RoHS compliant and UL Listed, with CSA Certified support, ensuring safety and reliability across diverse markets. Designed for power semiconductor devices and motor drives, it integrates smoothly with the Eaton Edison series and standard panels. By aligning with common procurement practices and reducing maintenance costs, this fuse offers tangible business value without sacrificing protection.
Product Information
Extended Description
JHL45 Eaton: Eaton Edison JHL high speed fuse, 600 Vac, 450 Vdc, 45A, 200 kAIC, Non Indicating, Melamine tube with silver fuse element
Product Name
Eaton Edison series JHL fuse
Catalog Number
JHL45
UPC
782634107248
Product Length/Depth
0.001 in
Product Height
0.001 in
Product Width
0.001 in
Product Weight
0.001 lb
Warranty
No warranty
Compliances
CE Marked RoHS Compliant
Certifications
CSA Certified UL Listed
Amperage Rating
45 A
Interrupt rating
200 kAIC
Voltage rating
600 Vac, 450 Vdc
Material
Melamine tube with silver fuse element
Packaging type
Standard
Fuse indicator
Non Indicating
Quantity
10
Used with
Power semiconductor devices
Bussmann series complete full line catalog no. 1007
Bussmann series complete full line catalog no. 1007
Bussmann series Fuseology
Eaton Specification Sheet - JHL45
Feature: 200 kAIC interrupt rating provides robust fault current handling, reducing equipment damage during short circuits. Business Impact: This minimizes panel downtime and replacement costs, maintaining production continuity. Application: Ideal for high-energy faults in power electronics and drives within automation systems. Feature: 600 Vac / 450 Vdc voltage rating ensures compatibility with both AC and DC power architectures. Business Impact: Enables a single protective device across mixed supply environments, simplifying wiring schemes and procurement. Application: Widely used in industrial drives and power conversion setups. Feature: 45 A amperage rating delivers precise protection for medium-load circuits without nuisance tripping. Business Impact: Improves system availability and extends component life by preventing overfuse. Application: Suitable for power semiconductor devices and controlled loads in automation panels. Feature: Melamine tube with a silver fuse element offers reliable, fast-acting performance. Business Impact: Reduces fault energy and damage, lowering maintenance costs over time. Application: Fits in high-speed fuse applications within Eaton Edison products. Feature: Non-indicating fuse with standard packaging (10 per package) supports straightforward replacement and stocking. Business Impact: Streamlines maintenance and reduces spare-part complexity. Application: Beneficial for OEMs and panel builders deploying Edison line protections. Feature: Certifications and compliance (CE RoHS, UL Listed, CSA Certified) provide regulatory assurance. Business Impact: Accelerates approvals and aligns with industry standards, minimizing risk during audits. Application: Appropriate for regulated industrial environments and global deployments.
Get a Quick Quote for a Eaton JHL45
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton JHL45?
Enquire Now
FAQs
Yes. The JHL45 is designed for use with Eaton Edison series devices and standard industrial panels. It supports power semiconductor protection in both AC and DC circuits (600 Vac / 450 Vdc) and ships in standard packaging for easy stocking and replacement during panel upgrades.
Key specs include 45 A current rating, 200 kAIC interrupt rating, and a voltage rating of 600 Vac / 450 Vdc. The 200 kAIC rating indicates robust fault current handling, reducing damage to drives and power electronics during short-circuit events and improving system reliability.
Yes. The 600 Vac / 450 Vdc rating, 45 A current rating, and high interrupt capability make it suitable for motor drives and power semiconductor devices in renewable energy inverters and related automation applications, where fast fault interruption minimizes equipment damage and downtime.
The JHL45 carries UL Listed, CSA Certified, and CE RoHS compliance. These certifications support safety and regulatory compliance across markets, simplify procurement for regulated environments, and aid in passing audits and inspections without additional verification.
By delivering fast, reliable overcurrent protection with high fault-current tolerance, JHL45 reduces equipment damage and unplanned downtime. Its non-indicating design lowers replacement costs, while compatibility with the Edison series streamlines spares management and procurement efficiency in panel assemblies.
