Eaton JHL5 Edison High Speed Fuse - UL Listed
Part Number: JHL5
Quick Summary
Eaton Edison JHL fuse provides fast overcurrent protection for power semiconductor devices in industrial drives and IIIoT applications. Many engineers face nuisance tripping and costly downtime from slower protection devices, especially with fast-switching power electronics. It carries UL Listed and CSA Certified marks, RoHS compliance, and CE marking to meet global safety and environmental standards. Engineered for 600 Vac and 450 Vdc systems, JHL5 offers 200 kAIC interrupt rating, helping you reduce warranty risk and extend equipment life. The non-indicating design reduces field maintenance, while the melamine tube with a silver fuse element ensures reliable performance in demanding environments. Designed for easy integration with power semiconductor devices and standard packaging, it minimizes downtime during preventative maintenance.
Product Information
Extended Description
JHL5 Eaton: Eaton Edison JHL high speed fuse, 600 Vac, 450 Vdc, 5A, 200 kAIC, Non Indicating, Melamine tube with silver fuse element
Product Name
Eaton Edison series JHL fuse
Catalog Number
JHL5
UPC
782634107262
Product Length/Depth
0.001 in
Product Height
0.001 in
Product Width
0.001 in
Product Weight
0.001 lb
Warranty
No warranty
Compliances
RoHS Compliant CE Marked
Certifications
UL Listed CSA Certified
Amperage Rating
5 A
Interrupt rating
200 kAIC
Voltage rating
600 Vac, 450 Vdc
Material
Melamine tube with silver fuse element
Packaging type
Standard
Fuse indicator
Non Indicating
Quantity
10
Used with
Power semiconductor devices
