Eaton JHL6 Fuse - 200 kAIC Interrupt Rating, UL Listed
Part Number: JHL6
Quick Summary
The Eaton JHL6 fuse is a high-speed protection device for power semiconductor circuits in industrial controls. Choosing the right fuse can be challenging when dealing with fast switching, surge events, and compact enclosures. This component carries UL Listed, CSA Certified marks, and CE Mark RoHS compliance, ensuring global regulatory alignment. With a 600 Vac / 450 Vdc rating and a 200 kAIC interrupt capability, it delivers reliable protection for drives and power electronics. Using this fuse reduces downtime, simplifies procurement, and supports predictable maintenance in modern control panels. Engineers benefit from documented compatibility with Edison series devices and the melamine tube design.
Product Information
Extended Description
JHL6 Eaton: Eaton Edison JHL high speed fuse, 600 Vac, 450 Vdc, 6A, 200 kAIC, Non Indicating, Melamine tube with silver fuse element
Product Name
Eaton Edison series JHL fuse
Catalog Number
JHL6
UPC
782634107293
Product Length/Depth
0.001 in
Product Height
0.001 in
Product Width
0.001 in
Product Weight
0.001 lb
Warranty
No warranty
Compliances
CE Marked RoHS Compliant
Certifications
UL Listed CSA Certified
Amperage Rating
6 A
Interrupt rating
200 kAIC
Voltage rating
600 Vac, 450 Vdc
Material
Melamine tube with silver fuse element
Packaging type
Standard
Fuse indicator
Non Indicating
Quantity
10
Used with
Power semiconductor devices
Bussmann series complete full line catalog no. 1007
Bussmann series complete full line catalog no. 1007
Bussmann series Fuseology
Eaton Specification Sheet - JHL6
