Eaton JHL60 Fuse - 60A Class J, 600 Vac, UL Listed
Part Number: JHL60
Quick Summary
The Eaton JHL60 fuse is a high-speed Class J protection device designed to safeguard power semiconductor systems in industrial drives. Engineers often battle nuisance trips and unreliable protection that disrupts uptime during peak load transients. UL Listed, CSA Certified, and CE RoHS compliance provide regulatory assurance for global deployments. With a compact Edison-style form factor and standardized compatibility, it enables faster installation, predictable maintenance, and a lower total cost of ownership for drive and inverter applications.
Product Information
Extended Description
JHL60 Eaton: Eaton Edison JHL high speed fuse, 600 Vac, 450 Vdc, 60A, 200 kAIC, Non Indicating, Melamine tube with silver fuse element
Product Name
Eaton Edison series JHL fuse
Catalog Number
JHL60
UPC
782634107309
Product Length/Depth
3 in
Product Height
1 in
Product Width
2 in
Product Weight
0.012 lb
Warranty
No warranty
Compliances
CE Marked RoHS Compliant
Certifications
CSA Certified UL Listed
Amperage Rating
60 A
Interrupt rating
200 kAIC
Voltage rating
600 Vac, 450 Vdc
Material
Melamine tube with silver fuse element
Packaging type
Standard
Fuse indicator
Non Indicating
Quantity
10
Used with
Power semiconductor devices
JHL60~Edison High Speed Class J Fuse
JHL60~Edison High Speed Class J Fuse
Bussmann series Fuseology
Eaton Specification Sheet - JHL60
The 60 A amperage rating and 600 Vac voltage capability deliver precise protection for high-energy power electronics, reducing the risk of cascading failures and enabling selective coordination with downstream devices. This supports tighter safety margins in motor drives and inverter assemblies, translating to measurable uptime improvements and lower repair costs in automated production lines. The 200 kAIC interrupt rating ensures fast fault clearance for short-circuit events, protecting both equipment and personnel while meeting stringent industrial protection standards. The melamine tube with a silver fuse element provides reliable performance in typical factory environments, with robust arc-quenching characteristics that minimize downstream damage. Non-indicating design reduces component cost and footprint, while clear specifications and Edison-series compatibility simplify installation and spares management for maintenance teams. Packaging of ten units per order supports scalable stocking for multi-draw operations, aligning with procurement workflows and Lean inventory practices. Compliance with CE, RoHS, UL and CSA standards reinforces worldwide deployment confidence, enabling broader project reach for electrical protection and circuit control needs.
