Eaton JHL90 Fuse - 600 Vac, 90 A, 200 kAIC - UL Listed
Part Number: JHL90
Quick Summary
The Eaton JHL90 fuse is a high-speed Class J device designed to protect power electronics and motor drives in industrial automation. Engineers often wrestle with nuisance trips and delayed fault isolation that drive downtime and service costs; this fuse minimizes both by delivering fast interruption and selective protection for critical loads. UL Listed, CSA Certified, RoHS Compliant CE Marked — these certifications support regulatory compliance and cross-border procurement. In automation panels and power electronics racks, the JHL90 provides reliable protection without complicating maintenance. For growing control architectures, its compatibility with Edison series devices supports scalable, safe protection across evolving power systems.
Product Information
Extended Description
JHL90 Eaton: Eaton Edison JHL high speed fuse, 600 Vac, 450 Vdc, 90A, 200 kAIC, Non Indicating, Melamine tube with silver fuse element
Product Name
Eaton Edison series JHL fuse
Catalog Number
JHL90
UPC
782634107354
Product Length/Depth
0.001 in
Product Height
0.001 in
Product Width
0.001 in
Product Weight
0.001 lb
Warranty
No warranty
Compliances
RoHS Compliant CE Marked
Certifications
UL Listed CSA Certified
Amperage Rating
90 A
Interrupt rating
200 kAIC
Voltage rating
600 Vac, 450 Vdc
Material
Melamine tube with silver fuse element
Packaging type
Standard
Fuse indicator
Non Indicating
Quantity
5
Used with
Power semiconductor devices
JHL90~Edison High Speed Class J Fuse
JHL90~Edison High Speed Class J Fuse
Bussmann series Fuseology
Eaton Specification Sheet - JHL90
Feature → Business Impact → Application: The JHL90 is a high-speed Class J fuse with a 90 A rating and a 200 kAIC interrupt capacity, delivering rapid fault clearance to protect power semiconductors and drives, reducing damage and downtime in motor control applications. This translates to lower repair costs and improved equipment uptime in manufacturing lines and material-handling systems. Feature → Business Impact → Application: Rated for 600 Vac and 450 Vdc, it supports both AC mains and DC bus protection in automation panels, enabling compliant, robust protection in machine control, servo drives, and power electronics assemblies. Feature → Business Impact → Application: Non-indicating design with a melamine tube and silver fuse element offers cost-effective protection where indicators aren’t required, simplifying installation in densely packed control cabinets and reducing stocking complexity. Feature → Business Impact → Application: UL Listed, CSA Certified, and RoHS CE compliant provide regulatory assurance and easy supplier qualification, streamlining audits and panel builds for automotive, packaging, and process industries. Feature → Business Impact → Application: Packaging includes five units per pack, aiding maintenance planning and inventory control for field service and repair operations in industrial facilities. Feature → Business Impact → Application: Used with power semiconductor devices, it supports safer startups and longer equipment life in drive systems, power supplies, and renewable energy interfaces.
