Eaton JJN-1000 fuse - Class T, 200 kAIC at 300 Vac
Part Number: JJN-1000
Quick Summary
The Eaton JJN-1000 fuse provides current-limiting protection for VFD-powered motor drives. This device is designed to minimize disruptive faults in high-current drive systems, helping keep production lines running. Engineers often face nuisance blowing and arc energy during fault events; a properly selected Class T fuse reduces downtime and wasteful rework. CE marked and RoHS compliant, it meets global safety and environmental requirements for industrial equipment. As part of the Bussmann series, the JJN-1000 combines reliable protection with straightforward installation, space efficiency, and compatibility with bolted blade end circuitry. For facilities seeking robust, scalable protection, this fuse delivers predictable response and long service life in demanding automation environments.
Product Information
Extended Description
JJN-1000 Eaton: Eaton Bussmann series JJN fuse, Current-limiting, VFD line protection, 1000 A, Class T, Non-indicating, Bolted blade end x bolted blade end, 100 kAIC at 170 Vdc, 200 kAIC at 300 V, Standard, 1, 300 V, 170 Vdc
Product Name
Eaton Bussmann series JJN fuse
Catalog Number
JJN-1000
UPC
051712627191
Product Length/Depth
4 in
Product Height
2 in
Product Width
2 in
Product Weight
1.45 lb
Warranty
Not Applicable
Compliances
CE Marked RoHS Compliant
Amperage Rating
1000 A
Interrupt rating
200 kAIC at 300 Vac 100 kAIC at 170 Vdc
Voltage rating
300 Vac, 170 Vdc
Packaging type
Standard
Class
Class T
Connection
Bolted blade end x bolted blade end
Fuse indicator
Non-indicating
Quantity
1
Bussmann Full Line Catalog
Bussmann Full Line Catalog
RoHS Search Tool
Bussmann series Fuseology
JJN-100~TRON FAST ACTING FUSE CLASS T
Feature: 1000 A amperage rating enables reliable protection for high-current circuits in motor drives. Benefit: minimizes fuse-related outages and equipment damage, improving line uptime. Application: VFD protection in heavy industrial automation. Feature: Interrupt ratings of 200 kAIC at 300 Vac and 100 kAIC at 170 Vdc offer strong fault-current handling. Benefit: protects costly drives and cables from high-energy faults, reducing collateral damage. Application: short-circuit events in high-power automation installations. Feature: Class T fast-acting design (TRON FAST ACTING) supports precise protection timing. Benefit: faster response to surge conditions, lowering energy let-through and arc energy. Application: motor-start and drive protection in fast-moving production lines. Feature: Bolted blade end x bolted blade end connections deliver secure, maintenance-friendly mounting. Benefit: simplifies replacement in tight panels and minimizes contact resistance. Application: retrofit and new installations in control panels. Feature: Non-indicating fuse with standard packaging and 4 in length, 2 in height, 2 in width. Benefit: compact footprint fits in crowded enclosures and reduces panel size. Application: space-conscious control cabinets in manufacturing facilities. Feature: RoHS compliant and CE marked underline regulatory compliance. Benefit: supports global procurement standards and audits, easing compliance costs. Application: equipment destined for regulated markets and multi-site deployments. Together these characteristics enable a robust, scalable protection solution for industrial controls, while aligning with long-term maintenance strategies and cost-of-ownership goals.
